Hitachi DH 24 PF - Manual (Page 25)

25
English
11. Dust cup, Dust collector (B)
Dust cup
Code No. 971787 Dust collector (B)
Code No. 306885
12. Hammer grease A
1.1 lbs. (500 g) (in a can) Code No. 980927
0.15 lbs. (70 g) (in a green tube) Code No. 308471
0.07 lbs. (30 g) (in a green tube) Code No. 981840
NOTE:
Specifications are subject to change without any obligation on the part of the
HITACHI.
Bit No. Chuck adaptor (D)
(SDS-plus shank)
Code No. 303624
10. Driving Screws (Rotation only)
Phillips Driver Bit
Bit No. Screw Size Length Code No.
No. 2 1/8" ~ 3/16" (3 – 5 mm) 1” (25 mm) 971511Z
No. 3 1/4" ~ 5/16" (6 – 8 mm) 1” (25 mm) 971512Z
Chuck wrench
⅜ 1/2" (13 mm) drill chuck ass’y (includes chuck wrench) and chuck (for drilling
into steel or wood)
9. Drilling holes (Rotation only)
Drill chuck (13VLD–D)
(includes chuck wrench)
Code No. 321813 Chuck adaptor (D)
(SDS-plus shank)
Code No. 303624
