CONTINUED
Insert the connector securely into
the socket.
Hook the retaining tab on the
inner side of the lid against the
retaining tab of the connector to
prevent disconnection during
operation.
Your vehicle has a class 3 trailer
hitch as standard equipment.
The 7-pin trailer connector is needed
for the trailer lights. To connect the
connector, do this:
Make sure the connector and the
socket are free of dirt, moisture,
or other foreign material.
Open the socket lid by pulling it up.
Also see page for trailer-related
information.
1.
2.
3.
4.
299
Except RT models
Towing Equipment
Towing a Trailer
Connecting the Trailer Connectors
D
riv
ing
301
TRAILER HITCH
7-PIN TRAILER CONNECTOR
7-PIN TRAILER CONNECTOR
LID
RETAINING
TAB
SOCKET
RETAINING TAB
2009 Ridgeline
