Parts
Model 210–208, Series F
Displacement Pump
Includes items 13–49
Ref Part
. y t Q n o i t p i r c s e D . o N . o N
13 100–127 NUT, hex; 5/8–11 4
14 100–128 LOCKWASHER, spring; 5/8” 4
15* 100–579 PIN, cotter; 1” (25.4 mm) long 4
16 † 101–178 BALL; 1.25” (32 mm) dia.;
chrome steel
1
18 † 101–718 BALL; 2” (51 mm) dia.;
chrome steel
1
24* 111–334 O-RING. PTFE 2
25 104–272 CAPSCREW, socket hd;
3/8–24 x 1–1/2” (38 mm) long
4
28 161–599 PIN, ball stop; carbon steel 2
30 166–597 SPACER, packing, carbon steel 1
31* 188–846 PACKING, cup; UHMWPE 2
32 171–692 ROD, tie 4
35 171–696 GUIDE, piston; carbon steel 1
36 217–478 ROD, displacement; carbon steel 1
38 181–269 CYLINDER, stainless steel 1
39 186–054 PACKING NUT/WET–CUP
carbon steel
1
41 186–055 HOUSING, outlet; ductile iron 1
42 223–437 HOUSING, intake valve;
carbon steel
1
43 223–438 RETAINER, piston;
carbon steel, with carbide seat
1
44* 104–260 GLAND, male; carbon steel 1
45* 108–845 V-PACKING; UHMWPE 4
46* 104–263 V-PACKING; leather 2
47 † 186–056 BEARING; PEEK 1
48 172–477 TAG, warning 1
49 110–728 GASKET; buna–N 1
* Included in Repair Kit 223–439.
** Recommended spare parts. Keep these spare parts on
hand to reduce down-time.
Extra warnings available at no charge.
Packing Conversion Kit 224–443
Use to convert pump to UHMWPE and PTFE pack-
ings. Order kit separately. Includes:
Part
No.
Description Qty
100–103 PIN, cotter; 15.” (38 mm) long 1
100–579 PIN, cotter; 1” (25.4 mm) long 4
111–334 O-RING; PTFE 2
188–846 PACKING, cup; UHMWPE 2
104–260 GLAND, male 1
108–845 V-PACKING; UHMWPE 4
111–327 V-PACKING; PTFE 2
186–056 BEARING, PEEK 1
Technical Data
Maximum Fluid Working Pressure 1000 psi . . . . . . . . .
(70 bar, 7.0 MPa)
Fluid Outlet Size 1–1/2” npt . . . . . . . . . . . . . . . . . . . . . . .
Fluid Inlet Size 2” npt . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wetted Parts 303 Grade Stainless Steel, . . . . . . . . . . . .
Carbon Steel, Chrome Steel,
Chrome, Zinc, and electroless Nickel Plating,
Buna-N, Tungsten Carbide, Nylon,
Ultra-High Molecular Weight Polyethylene,
Leather, PTFE , Polyetheretherketone
Manual Change
Summary
Assembly
Changed Part
Status Ref.
No. Part No. Name
210–208 old
new 31
31 178–507
188–846 packing cup
packing cup
The series of this unit was changed from E to F.
