SPECIFICATIONS

Technical Specifications

Recording:

Rotary two-head helical scan azimuth recording

Video:

NTSC

color

EIA

standard

Cassette:

VHS

type

Heads:

4 video heads 2 for SP, 2 for EP

hi-fi

audio

heads

1 full track audio/video erase head

1 combination head for control track, audio erase

and record/play (3 heads/single housing)

Tape Speed:

33.35mm / sec (SP), 16.67mm / sec (LP)(playback only),

11.12mm

sec

(EP)

Tape

Width:

12.7

RF Output:

Channel 3 or 4

RF Input:

UHF/VHF 75 ohm

Tuning Range:

VHF LOW CH, 2 - 6 (54MHz - 88MHz)

VHF MID CH, A-5 - A-1 and A-I (90MHz - 174MHz) CATV

VHF HIGH CH, 7 - 13 (174MHz - 216MHz)

VHF SUPER CH, J - W (216MHz - 300MHz) CATV

VHF HYPER CH, W+1 - W+28 (300MHz - 468MHz) CATV

UHF CH, 14 - 69, W+29 - W+84 (470MHz - 806MHz)

Video Input:

1-2 Vp-p 75ohm unbalanced

Video Output:

1 Vp-p 75ohm unbalanced

Audio Input

316mV rms (-7.8dB) 50 kohm

Audio Output

316mV rms (-7.8dB) 1.5 kohm

Video Recording S/N:

Better than 45dB (SP), better than 40dB (EP)

Horizontal Resolution:

240 lines (SP), 220 lines (LP)(playback only), 230 lines (EP)

Audio Response:

50Hz - 10kHZ (SP), 100Hz - 6kHZ (EP)

Audio S/N:

Better than 43dB (SP), better than 40dB (EP)

Hi-Fi Audio:

Frequency Range:

20 Hz to 20 kHz

Dynamic

Range: 90

Wow and Flutter:

Less than 0.005% WRMS

Power

Input:

AC120V

60Hz

Power Consumption:

28W nominal

Cabinet Size:

14-15/16" (W) x 3-1/4" (H) x 12-11/16" (D)

38.0cm (W) x 8.2cm (H) x 32.3cm (D)

Weight:

11.7

lbs.

(5.3

kg)

Accessories:

1 coaxial cable (Part No. 5861141)

1 remote control unit (Part No. 5616491), 2 AA batteries

For information about how to obtain these accessories, please call TOLL FREE 1-800-448-2244 for your
nearest Hitachi Authorized Parts Distributor in the continental United States. For ALASKA and HAWAII,
please contact the nearest Hitachi Regional office.
