Part names
Remote control
Back of
the remote control
(1)
(3)
(5)
(7)
(9)
(10)
(11)
(14)
(16)
(18)
(19)
(22)
(24)
(26)
(2)
(4)
(6)
(8)
(12)
(13)
(15)
(17)
(21)
(20)
(23)
(25)
(27)
(28)
(1)
COMPUTER button (18)
(2)
MY SOURCE/DOC.CAMERA button (18, 46)
(3)
VIDEO button (18)
(4)
STANDBY/ON button (16, 17)
(5)
AUTO button (21)
(6)
SEARCH button (19)
(7)
ASPECT button (19)
(8)
BLANK button (23)
(9)
FREEZE button (23)
(10)
MAGNIFY - ON button (23)
(11)
MAGNIFY - OFF button (15, 23)
(12)
VOLUME + button (18)
(13)
VOLUME – button (15, 18)
(14)
KEYSTONE button (22)
(15)
MUTE button (18)
(16)
MY BUTTON - 1 button (46)
(17)
MY BUTTON - 2 button (46)
(18)
FOCUS – button (21)
(19)
FOCUS + button (21)
(20)
D-ZOOM – button (20)
(21)
D-ZOOM + button (20)
(22)
POSITION button (20, 23)
(23)
MENU button (24, 25)
(24) ▲/▼/◄/► cursor buttons (24, 25)
(25)
ENTER button (24, 25)
(26)
ESC button (15, 24, 25)
(27)
RESET button (15, 24, 25)
(28) Battery cover (14)
