Technical Specifications

Basic Features

Operating System:

BT & BT/ WLAN Configurations:
GSM Configurations:

Windows CE 5.0
Windows Mobile 6.0

Development Environment:

Honeywell SDK for Windows Mobile 6.0

Supported Software:

SOTI MobiControl (remote device management), PowerNet

™

Terminal Emulation (TNVT, 3270, 5250), and ITScriptNet

™

Installed Applications:

Honeywell Power Tools and Demos and ITScriptNet Ready-To-Go applications

CPU:

Samsung 2440 400 MHz

Memory:

128MB RAM X 128MB Flash

Mass Storage:

BT & BT/WLAN Configurations:
GSM Configurations:

User-accessible memory expansion slot for SD or MMC flash memory cards
User-accessible microSD™/microSDHC™

Display:

2.8 in. 1/4 VGA, 240 X 320, TFT color display with touch screen

Keyboards:

29-key numeric keyboard with shifted alpha and six(6) programmable keys
38-key alpha keyboard with shifted numeric and two(2) programmable keys
Backlit

Sound/ Voice:

On-board speaker, microphone, and standard 2.5mm headset jack

Communications:

RS-232/USB connector, IrDA port

Power:

Li-ion battery 3.7V / 2200 mAh / 8.1 Wh (standard) OR Li-ion battery 3.7V / 3240 mAh / 12.0 Wh (optional)

Charging:

5.0V DC input through side access or USB/Serial connector

Charging Peripherals:

AC wall adapter, Charge/Communication Cable, HomeBase: Single-bay terminal charger, QuadCharger: Four-bay battery charger

Imager Scanner Engines

Available Engines:

5300SR VGA Area Imager with High-Vis bracket aimer
Caution - use of controls or adjustments or performance of procedures other than those specified herein may

result in hazardous radiation exposure.

1D Symbologies:

Codabar, Code 3 of 9, Code 11, Code 32, Pharmaceutical (PARAF), Code 93, Code 128, EAN with Add-On, EAN with Extended

Coupon Code, EAN-8, EAN-13, GS1-128, GS1 Databar, Interleaved 2 or 5, ISBT 128, Matrix 2 of 5, MSI, Plessey, PosiCode,

Straight 2 of 5 IATA, Straight 2 of 5 Industrial, Telepen, Trioptic Code, UPC, UPC-A, and UPC-E

2D Symbologies:

Aztec, Codablock, Code 16K, Code 49, Composite, Data Matrix, GS1 Databar, MaxiCode, Micro PDF, OCR, PDF417, and QR Code

Composite Codes:

Aztec Mesa, Codablock F, EAN·UCC, GS1 Databar-14

OCR:

OCR-A, OCR-B, OCR-US Money Font

Postal Codes:

Postnet and most international 4 state codes, Australian Post, British Post, Canadian Post, China Post, Japanese Post, KIX

(Netherlands) Post, Korea Post, Planet Code

Wireless

WWAN (optional):

Quad Band: GSM 850/900/1800/1900MHz, GSM release 99, EDGE multi-slot class 12, GPRS multi-slot class 12

WLAN (optional):

802.11b/g

WLAN Security:

WEP, WPA Personal/Enterprise, WPA2 Personal/Enterprise, EAP-TLS, TTLS, LEAP, PEAP, WiFi (WPA2), Cisco CCX v4 (pending)

WPAN (standard):

Bluetooth Class 2, version 1.2

Co-Located/Operational:

Three radios: WPAN/WLAN/WWAN

Physical

Operating Temperature:

14° to 122°F (-10° to 50°C)

Charging Temperature:

32° to 104°F (0° to 40°C)

Relative Humidity:

95% humidity (non-condensing)

Construction:

High impact resistant PC/ABS housings Magnesium alloy internal chassis with component shock mounts

Structural:

5 ft. (1.5m) multiple drops to concrete, all axis, and across operating temperature range

ESD:

Air: +/- 12k Vdc, Direct: +/- 8k Vdc

Environmental:

IP54 rating rated for blown dust and water intrusion

Dimensions:

BT & BT/WLAN Configurations:
GSM Configurations:

7.0 in. long X 2.7 in. wide X 1.7 in. deep (17.8 cm. long X 6.9 cm. wide X 4.2 cm. deep)
7.1 in. long X 2.7 in. wide X 1.9 in. deep (18 cm. long X 6.9 cm. wide X 4.7 cm. deep)

Weight:

BT & BT/WLAN Configurations:
GSM configurations:

Approximately 11.7 oz./332g
Approximately 14.3 oz./406g

Regulatory & Compliance:

Safety: cUL 60950, NOM, EN60950, BSMI CN14336, CCC GB4943, PSB, SIRIM
EMC: FCC Part 15 Class B, ICES-003, EN301 489-1, EN301 489-17, EN55022, EN55024, BSMI CNS13438, CCC GB9254, MIC,

AS/NZS 3548, FCC Parts 22H & 24H, FCC SAR OET 65, EN301511, RSS-132/133
Radio: FCC 15.247, RSS-210, COFETEL, EN300 328-1, EN300 328-2, SRRC ETS 300 328, IDA, SIRIM, MIC, ARIB STD-T33 &

T66, AS/NZS 4771

Microsoft, Windows, and the Windows Logo are registered trademarks of Microsoft Corporation. The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and
licensed to Honeywell International Inc. microSD and microSDHC are trademarks.
Dolphin products have no affiliation with Honeywell branded batteries/chargers, which are exclusively distributed by Global Technology Systems pursuant to a license
agreement.

76-CE-DS Rev H 9/08
