7 43007-01
operation
6. Plug the unit into a 120V electrical outlet and press the UP key. The air purifier
will start with a low blower speed.
7. Use the UP/DoWN keys to adjust the blower speed to the desired level (0 = off,
1 = Sleep, 2 = Active, 3 = Turbo Clean). Refer to Fig. 8.
5. Place the front grill back onto the unit. First, line up the tab on the bottom of
the grill with the recess on the purifier base and then push the top of the grill
forward until it is closed. Refer to Figs. 6 and 7. NoTE: This unit will not operate
unless the grill is in the correct position.
Fig. 8
Fig. 6 Fig. 7
TAB
RECESS
LINE UP TAB WITH
RECESS IN BASE
