02/05 P/N 21163610
25
9. Insert bolt (29) through left side
upper elevator tube (35), then
stretch spring (33) onto bolt (29).
Insert bolt (29) through right side
upper elevator tube (35) and
secure with nut (31).
10. Roll completed assembly to desired position. Fill tank with water (approx.
34 gallons (129 Liters)) or sand (approx. 280 lbs. (128 kg)) and snap cap
(41) in place. Secure assembly to ground using rope (44) and tie down
stake (45).
BALLAST
BALLAST
BALLAST
45
41
44
USE EYE PROTECTION
WHEN INSTALLING
SPRINGS.
WARNING!
ADD TWO GALLONS (7.6
LITERS) OF NON-TOXIC
ANTIFREEZE IN SUB-
FREEZING CLIMATES.
CAUTION!
DO NOT LEAVE
ASSEMBLY UNATTENDED
WHEN EMPTY; IT MAY TIP
OVER.
WARNING!
35
33
31
35
3
29
33
