5-
Z Z
The Top
Z Z
is displayed when the heating or cooling system is
running.
The Bottom
Z Z
is displayed when the Auxiliary heat is on.
6- COOL
COOL is displayed when the system is in Cool mode.
7- AUTO
AUTO is displayed when in automatic changeover mode.
8- HEAT
HEAT is displayed when the system is in Heat mode.
EM HEAT is displayed when the Emergency Heat is on.
9- FAN
FAN is displayed when the fan is set to run continuously.
10- OFF
OFF is displayed when the system is in the Off mode.
11- REMOTE
REMOTE is displayed when the last command received by the
thermostat was sent by a remote system.
12- Period Indicators
MORN , DAY , EVE , or NITE is displayed when scheduled
temperature changes are made by the thermostat programs.
8
