Washing sequence
8
Figure 4
Figure 1
Spin timer Wash timer
(To set to below 2 minute,
first set to 6 minute then
turn it back. it can increase
the service life of the timer).
(To set to below 1 minute,
first set to 2 minute then
turn it back. it can increase
the service life of the timer).
Wash
Figure 3
Figure 2
Inlet selector
Wash selector
(Standard current,
strong current)
1 Inlet selector
(1) Set fill selection to Wash side . ( Figure 1 )
(2 ) Adjust water level rod to a position as needed.
2 Fill water and add solved powder detergent until
water reaches a suitable level. ( Figure 2 )
It begin to wash to dispense detergent uniformly.
3 Put in the wash load, and supplement water
as necessary.
4 Select the current
Select the strength of the current according to
the laundries. (Figure 3)
5 Select the washing time
Select the washing time according to the
laundries. (Figure 4)
6 After washing,set the DRAIN SELECTOR
at DRAIN .(Figure 5)
WASH SPIN
WASH TIMER
DRAIN SELECTOR
Figure 5
WASH SPIN
Drain selector
(Do not set drain selector
on Drain position during
washing)
SPIN TIMER WASH SELECTOR DRAIN SELECTOR
4
3
2
1 5
OFF OFF
DRAIN DRAIN
12
9
6
3 15
OFF OFF
WASH TIMER
Spin timer
(To set to below 1 minute,
first set to 2 minute then
turn it back. it can increase
the service life of the timer).
Drain selector
SPIN TIMER DRAIN SELECTOR
4
3
2
1 5
OFF OFF
DRAIN DRAIN
STRONG
STANDARD
WASH SELECTOR
DRAIN
OFF
OFF
3
6
9
12
15
