"START/PAUSE" button
After the power is switched on, press it to
start the machine
During working, push it to pause.
During pause, push this button to restart
and go on working
Connection between the water inlet hose and the washer
1. Do not take off the water absorption cushion. Please check if the
cushion is dropped or damaged before each usage. If it happens
please contact our after-sale department immediately.
2 .Put the nut of the water inlet hose on the valve jointer.
3 .Fasten the nut. Swing it gently to confirm if it's suitable.
nut of the water
inlet hose
jointer of the
water inlet valve water absorption
cushion.
Connection between the jointer of the water inlet hose and the water inlet hose
1. Push down the slider. Insert the water inlet hose into the jointer.
2 Hang the lock lever to the jointer. Release the slider till a click
sound is heard.
Locking level
the jointer of the
water inlet hose
Slider
Check the connection between the jointer of the water inlet hose
and the water faucet
1. Swing the hose gently to confirm if it is fastened stable.
2.After installation, open the faucet to check if it leaks.
3.Do not bend the hose with overstrain.
4.Before each usage please check if the connection
between the jointer of the water inlet hose and the
water faucet, and the installation of the water inlet
hose are firm, so as to prevent dropping from
improper installation position.
Dismantle the water inlet hose
1. Close the water faucet.
2. Press the locking lever. Push down the slider. Then pull of the water inlet
hose.
If the machine is used frequently, the jointer of the water inlet hose can be
kept
on the faucet to prevent damaging the fixing screw.
Locking level
Slider
Description of operation button
4 Use the operation button
Indicator mode and meaning
Flashing, indicating the running program
On, indicating the program about to run or the selection mode
a
" " RINSE button "SOAK "button "WASH/SPEED " button "SPIN/SPEED " button
Press the Soak button to select a soak
procedure.
The button is unavailable from the
Saving,Speedily, Standard, Woollen,
Carpet and Delicate programs.
Press the Wash button to select a
wash .
procedure
The button can be used to select
the desired wash time( 0,6,9,12,15
minutes) from the Normal and
Jean program.
For the Normal Jean program,
press the button for 2 seconds to
start wash speed selection. The
speed from 1 to 4 is available for
selection. The default value is 2.
Press the Rinse button to select a
rinse
. procedure
The button can be used to select
the desired number of rinse cycles,
(0, 1, 2 , 3 times )from the Normal
program or the Jean program.
While the
"Overflow" digitron is
lighting,the program of the overflow
rinse has been selected.
Press the Spin/Speed button to
select a spin
. procedure
The button can be used to select
the desired spin time(1,3,5,7
minutes )from the Normal program
or the Jean program.
For the Normal or Jean program,
press the button for 2 seconds to
start spin speed selection. The
speed from 1 to 4 is available for
selection. The default value is 2.
Soak
Wash
Overflow
Wash/spin
speed
•
•
Rinse Spin
SPIN
SPEED RINSE
SOAK
WASH
SPEED
STA RT
PAU SE
The button can be used to select the
desired soak time( 10, 20 minutes)
from the Normal and Comforter
programs.
The button is unavailable from the
Saving,quickwash,posthaste Standard,
Carpet, Woollen programs.
The button is unavailable from the
Saving,quickwash,posthaste Standard,
Carpet, Woollen programs.
The button is unavailable from the
Saving,quickwash,posthaste Standard,
Carpet, Woollen programs.
