Hitachi C 7BMR User Manual
Page 39
39
Item
No.
Part Name
Q’TY
1
GEAR COVER
1
2
HITACHI LABEL
1
3
CUSHION
1
4
FLAT HD. SCREW M6
×
20
1
5
NEEDLE BEARING (HK1010)
1
6
SPINDLE AND GEAR SET
1
7
BEARING HOLDER
1
8
SEAL LOCK FLAT HD. SCREW M5
×
14
2
9
BALL BEARING 6003VVCMPS2L
1
10
BUSHING
1
11
LOWER GUARD
1
12
RETURN SPRING
1
13
BEARING COVER
1
14
SEAL LOCK FLAT HD. SCREW M4
×
10
2
15
WASHER (A)
1
16
TCT SAW BLADE 185MM-D16 HOLE-NT24
1
17
WASHER (B)
1
18
BOLT (W/FLANGE) M8
×
15.5
1
19
LEVER
1
20
MACHINE SCREW (W/WASHERS) M4
×
12
1
21
SEAL LOCK SCREW (W/SP. WASHERS) M6
×
8
1
22
LEVER (A)
1
23
LOCK NUT
1
24
WASHER
1
25
HOUSING ASS'Y (INCLUD.27,41,42)
1
26
NAME PLATE
1
27
S HOLDER
1
28
BALL BEARING 6000VVCMPS2L
1
29
WASHER (A)
1
30
BRUSH TERMINAL
2
31
STATOR ASS'Y 120V (INCLUD.30,32)
1
32
TERMINAL M4.0
2
33
FAN GUIDE
1
34
ARMATURE ASS'Y 110V-120V (INCLUD.28,29,36,37)
1
35
LOCK LEVER
1
36
DUST WASHER (B)
1
37
BALL BEARING 6202VVCMPS2L
1
38
RUBBER RING
1
39
HEX. HD. TAPPING SCREW D5
×
50
2
40
CAUTION PLATE
1
41
HEX. SOCKET SET SCREW M5
×
82
42
BRUSH HOLDER
2
43
CARBON BRUSH
2
44
BRUSH CAP
2
Item
No.
Part Name
Q’TY
45
TAPPING SCREW (W/FLANGE) D4
×
10
1
46
SWITCH
1
47
PILLAR TERMINAL
1
48
HANDLE (A)
1
49
MACHINE SCREW (W/WASHERS) M5
×
50
3
50
HANDLE (B)
1
51
MACHINE SCREW (W/WASHERS) M5
×
25
1
52
TAPPING SCREW (W/FLANGE) D4
×
20
4
53
TERMINAL M4.0
1
54
TAPPING SCREW (W/FLANGE) D4
×
16
2
55
CORD CLIP
1
56
CORD ARMOR
1
57
CORD
1
58
SLOTTED HD. SET SCREW (SEAL LOCK) M6
×
8
1
59
BASE ASS'Y (INCLUD.58,60-65,67-69)
1
60
SEAL LOCK SCREW (W/SP. WASHERS) M6
×
14
1
61
LEVER (A)
1
62
LOCK NUT
1
63
WASHER
1
64
BEVEL PLATE
1
65
SEAL LOCK HEX. SOCKET SET SCREW M5
×
6
2
66
ROLL PIN D6
×
40
1
67
STEP PIN D6
×
13
2
68
BOLT (SQUARE) M6
×
20
1
69
LINK
1
70
BOLT (SQUARE) M6
×
20
1
501
BOX WRENCH 10MM
1
