What is what, What is what on a power cutter – Husqvarna 371K User Manual
Page 12
12
– English
WHAT IS WHAT?
1.
Cylinder cover
2.
Muffler
3.
Fuel tank
4.
Rear handle
5.
Choke
6.
Throttle catch
7.
Stop switch
8.
Cutting head
9.
Cutting arm
10. Belt tensioning screw
11. Cutting blade
What is what on a power cutter?
12. Throttle
13. Combination spanner
14. Air filter cover
15. Blade guard
16. Starter handle
17. Operator’s manual
18. Adjustment lever for blade guard
19. Front handle
20. Starter
21. Decompression valve
17
13
11
8
10
9
12
21
2
15
18
4
7
3
16
20
1
19
14
5
6
Cutters can be dangerous !
For safe operation follow all safety
precautions in operator´s manual.
WARNING
371K 71 cc VHVO71UB25RC
IMPORTANT ENGINE INFORMATION
THIS ENGINE CONFORMS TO 1997 U.S. EPA EMISSION
REGULATION FOR SMALL NONROAD ENGINES.
REFER TO OPERATOR´S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.
HUSQVARNA AB HUSKVARNA SWEDEN
