Eagle Pump & Compressor EGA530 User Manual
Page 7
7
Wear hearing protection.
Wear eye protection.
Wear respiratory protection.
Read the instruction manual
12
802-1
Valve Plug
1
1
4451-1
Grip
1
14
44514-4
O-Ring
1
15
44515-1
Exhaust Ring
1
16
445-1
Retainer Ring
1
17
446-1
O-Ring
2
18
447-1
Air Regulator
1
19
448-1
O-Ring
1
20
449-1
Air Inlet
1
21
4441-1
Spring
1
22
54941-1
Ball
4
2
14515-1
Bearing
1
24
14516-2
End Plate
1
25
14517-1
Ball
2
26
14518-2
Rotor
1
27
14519-1
Rotor Blade
4
28
14520-2
Cylinder
1
29
14521-2
Bushing
1
0
14524-1
Pin
1
1
1452-1
Front Plate
1
2
14525-1
Bearing
1
14526-1
Collet Holder
1
4
14527-1
Retainer
1
5
4455-1
Housing Cap
1
6
14529-
Collet
1
7
1450-1
Collet Nut
1
8
1451-1
Wrench
2
Collet Size .....................................................................................................................1/4”
Air pressure (PSI) ............................................................................................................90
Average air consumption (CFM) .....................................................................................4.5
Free speed (RPM) .....................................................................................................22000
Air inlet (NPT) ................................................................................................................1/4”
Hose size (ID) ................................................................................................................/8”
