Escort PASSPORT SR7 - Manual (Page 3)

Table of Contents
Introduction
I
• Congratulations I
• Important Warning I
• Quick Reference Guide 4
Controls and Features 5-8
• Power and Volume Control 5
• Power-On Indication 5
• AutoMute 5
• Mute 5
• Remote Mute / Volume 5
• Auto / Highway / City Switch 6
• Display Brightness 6
• Audible Alerts 6
• Signal Strength Meter 7
• ExpertMeter 7
• SpecDisplay 8
• Optional Laser Shifters ™ 8
EZ-Programming 9-13
• How to use EZ-Programming 9
• Example of Programming 9
• Overview of Programming 10
• Details of Programming 11-13
Technical Details 14-19
• Interpreting Alerts 14-15
• How Radar Works 16
• How Laser Works 17
• How Safety Radar Works 18-19
Service 20-25
• Troubleshooting 20-21
• Service 22
• Warranty 22
• Specifications 25
3 2
Quick Reference Card
Passport SR7 Quick Reference Card
* Factory Default Settings
̄ Remove card along perforations ̄
̄
Remove card along perforations
̄
Press the REVIEW button
to go from one category
to the next
DISPLAY
PILOT LIGHT
(Power-on indication)
POWER-ON SEQUENCE
SIGNAL STRENGTH METER
AUTOMUTE
AUDIOTONES
CITY MODE SENSITIVITY
BRIGHTNESS
BANDS
Disp STD
Disp VERT
Pilot HWY
Pilot H
Pilot H.>
Pilot +
Pilot +.>
Pilot +>
Pilot V
PwrOn STD
PwrOn FST
Meter STD
Meter EXP
Meter SPC
aMute ON
aMute OFF
Tone STD
Tone LOUD
City STD
City LoX
City NoX
Brt AUTO
Brt MIN
Brt MED
Brt MAX
Brt DARK
Bands ALL
Bands MOD
X ON or OFF
K ON or OFF
Ka ON or OFF
LSR ON or OFF (or SHFT with ZR3)
SWS ON or OFF
Press the CHANGE button
to change your setting
within a category
* Standard display
Vertical display
* Full word: Highway or Auto or City
Letter: H or A or C
Letter with scanning dot
Symbol: + or • or --
Symbol with scanning dot
Scanning symbol
Vehicle voltage
* Standard power-on sequence
Fast power-on sequence
* Standard signal strength meter
ExpertMeter
SpecDisplay
* AutoMute on
AutoMute off
* Standard tones
Loud tones
* Standard City mode sensitivity
Low X band sensitivity in City Mode
No X band sensitivity in City Mode
* Brightness adjusts automatically
Minimum brightness when turned on
Medium brightness when turned on
Maximum brightness when turned on
Dark Mode when Passport turned on
* All bands enabled
One or more bands has been modified
Turn bands “ON” or “OFF” by
pressing the mute button
