Introduction
Open the packing
Overview
Introduction of back panel
R251 packing list:
1 x Sub Woofer
5 x satellite Speakers
3 x Audio Connecting Cord
1 x User's Manual
1
Sub Woofer
2
Satellite Speakers
3
4
5
User's Manual
6
Line In Port
7
Speaker Out
8
Power Switch
9
Power Cord
Inverse-phase hole
Audio connecting cord
Please check the speaker pattern marked on the package. Please contact the seller as soon as possible if you
find the speaker is not the pattern you want.
CONNECTING
