Product description
11
2
3
7
9
5
1
4
8
10
6
12
1 Control panel
2 Drawer with condensed water container
3 Lamp for inside light
4 Fine strainer (lint filter)
5 Large mesh filter (lint filter)
6 Micro-fine filter (lint filter)
7 Rating plate
8 Loading door (reversible)
9 Base door upstream of fluff filter and heat exchanger
10 Button for opening door in plinth
11 Air slots
12 Screwed feet (with height adjustment)
