Appendix A Router/Gateway Setup for Internet Viewing
To view Internet Camera across the Internet, you have to make sure Router/Gateway has
configured to pass incoming TCP/UDP connections from remote PC to the Internet Camera.
The Router/Gateway should set port forwarding or virtual server for the connections. Please
see the illustration as below.
Router/Gateway Port Forwarding/Virtual Server Setup
Name Protocol Port LAN IP
Setup 1 TCP 80 192.168.2.3
Setup 2 TCP 4321 192.168.2.3
Setup 3 UDP 13364 192.168.2.3
Setup 4 UDP 15973 192.168.2.3
Port Definition
Setup 1 It is the port of Web port. You have to configure the protocol to
“TCP”.
Setup 2 It is the port of Video port. You have to configure the protocol to
“TCP”.
Setup 3 It is the port for Internet Camera and Administrator Utility
communication. The protocol setting should be “UDP”.
Setup 4 It is the port for Internet Camera and Camera Viewer Utility
48
