23- ENG A08591
PARTS LIST
Key
No. Part No. Description
★ 1 ----- Shroud - Left
★ 2 ----- Shroud - Right
3 ----- Cylinder Head
▲ 4 CAC-1212 Tube Seal
▲ 5 ----- Head Gasket
6 Z-A08548 Valve Plate Assembly
7 DAC-269 Outlet Tube
▲ 8 ----- Gasket
9 Z-A04647 Sub Pump Assembly
◆ 9-8 ----- Rod Assembly
• 9-9 ----- Pre-Formed Compression Ring
9-10 ----- Connecting Rod Cap
• 9-11 D21127 Screw #10-24 x .563
+ 9-12 SSF-3147 Screw 3/8-16 x .375 UNC
• ◆ 9-13 ----- Cylinder Sleeve
10 CAC-1206-1 Hose Clamp
+ 14 SUDL-9-1 Screw #8-32 x .375/.344
+ 15 SSF-3156 Screw #10-9 x .500 (5)
16 A00765 Motor Cord
17 D25731 Isolator Pump (5)
+ 18 SSF-995 Screw #10-24 x .875 (4)
22 AC-0206 Isolator Tube
24 Z-D23701 Replacement Brushes
25 AC-0815 Timing Belt
Not Illustrated
◆ KK-4964 Connecting Rod Kit
• D30324 Ring Kit
▲ D30139 Gasket and Seal Kit
★ A06436 Left/Right Shroud Kit
+ KK-4929 Fastener Kit
