Specifications, Part Numbers, Accessories, cont’d
Accessories
These items can be ordered separately
Accessories Part number
VersaTools 1U rack shelf 60-190-20
Standard 1U rack shelf 60-190-01
Mini under-desk mounting bracket kit 70-212-01
Mini projector mounting kit 70-217-01
MediaLink Controller
MLC 206 (3-gang) (gray, black, white) 60-385-01, -02, -03
P/S 100 power supply 60-357-01
Cables
Plenum Comm-link cable Part number
50 feet, 100 feet, 200 feet 26-461-01, -02, -03
300 feet, 400 feet 26-461-05, -04
Conductor gauges in Extron Comm-Link cables
red & black single strands (for power/ground) 18 AWG
white & violet shielded single strands (for signals) 22 AWG
drain wire 24 AWG
Adapters
Adapters Part number
SVHSM-BNCF S-video male to
BNC female adapter (for MLS 103 SV) 26-353-01
or
or
or
A-6 A-7
Included Parts
These items are included in each order for an MLS switcher:
Included Part number
parts to reorder
MLS 100 A 60-497-01
MLS 103 V 60-497-02
MLS 103 SV 60-497-03
MLS 102 VGA 60-497-04
12VDC, 1 A external power supply
USA domestic version 70-055-01
World version 70-055-02
IEC power cord
Tweeker (small screwdriver)
Rubber feet
3.5 mm, 3-pole captive screw connectors 10-319-13
3.5 mm, 5-pole captive screw connectors 10-319-10
MLS 100 Series User’s Manual 68-652-01
MediaLink Control Software 29-052-01
