KFGC506J shown on right
(reference Use & Care Guide for 30” and 48” diagrams)
FUNCTION USE & LIGHT BEHAVIOR
Oven Start
Button Solid White Light
The Start Button will illuminate solid white when the most recent command was sent from the app and the appliance is
being controlled remotely. The light will turn off as soon as an action is taken on the appliance.
Pulsing White Light
The Start Button will flash white to prompt the user to press start after the Mode and Temperature have been selected.
If no action is taken after 2 minutes, a tone will sound and the unit will timeout and return to idle.
To exit idle, re-select a Mode and Temperature before pressing the Start Button.
Quick-Blinking White Light
If an invalid knob combination has been chosen and the Start Button is pressed, the Indicator Light will quickly blink and
a tone will sound to indicate that the chosen combination is invalid. See the Mode and Temperature Compatibility Table
for valid combinations.
Mode and
Temperature
Indicator Light Solid White Light
When a Mode or Temperature is selected, and the combination is valid, the Mode and Temperature Indicator Light
will illuminate white.
Solid Red Light
After a valid Mode and Temperature have been selected and the Start Button has been pressed, the Indicator Light
will turn red until the preheat is completed.
Solid White Light
The light will turn solid white and a tone will sound when the preheat is complete. If there is no preheat for a cycle,
the preheat completes immediately and the Indicator Light turns solid white.
Quick-Blinking White Light
If an invalid knob combination has been selected, the Indicator Light will blink and a tone will sound prompting the user to
select a valid combination. The Indicator Light will continue to blink and a tone will sound every 30 seconds until the error
is fixed or the unit will timeout after 2 minutes of inactivity and return to idle.
Pulsing Amber Light
The Indicator Light will pulse amber if the oven is undergoing a 100+ degree decrease in temperature
(i.e. changing from Bake 450°F to Bake 350°F) or if the oven is too hot to properly proof and needs to cool down.
WIFI Indicator
Light Solid White Light
The WIFI Indicator Light illuminates white when the unit is WIFI enabled allowing the user to monitor
the unit. All lights will turn off in idle even when the unit is connected to WIFI.
Remote Enabled
Indicator Light Solid White Light
The Remote Indicator Light illuminates white when the unit is remote enabled and the user can send instructions
to the unit. All lights will turn off in idle even when the unit is remote enabled.
Griddle Power
Indicator Light* Solid Blue Light
The Griddle Power Indicator Light illuminates blue when the griddle is powered on.
Griddle
Preheat Light* Blinking Blue Light
The Griddle Preheat Light flashes blue while the griddle is preheating.
Solid Blue Light
Once the preheat temperature has been reached, the Indicator Light turns solid blue.
LIGHT INDICATORS AND BEHAVIORS
WIFI Antenna Module
Oven Light Button
Mode and Temperature Knob and Indicator Light
Oven Start Button and Indicator Light
WIFI Indicator Light
Remote Enabled Indicator Light
SAID Label
COMMERCIAL-STYLE GAS RANGE
QUICK REFERENCE GUIDE
*on 48” models only
W11364680B
