RGB 130xi xi xi xi xi , 134xi xi xi xi xi , 150xi xi xi xi xi Appendix
Video input
Number/type .............................. 1 analog RGBHV, RGBS, RGsB,
RsGsBs
Connectors .................................... 1 15-pin HD male (150xi)
1 9-pin D male (130xi and 134xi)
Nominal level(s) .......................... Analog — 0.3V to 1.5V p-p
Maximum level(s) ....................... Analog — 1.5V p-p
Impedance .................................... 75 ohms or (for 130xi and 134xi) HI
Z, switchable - set to 75 ohms if no
local monitor is connected
Horizontal frequency ................. Autoscan 15 kHz to 125 kHz
Vertical frequency ....................... Autoscan 30 Hz to 120 Hz
Return loss .................................... -30dB @ 5 MHz
Maximum DC offset ................... 4.0V
Video throughput
Gain ............................................... Unity, 0.725V p-p, 0.750V p-p
Bandwidth .................................... 300 MHz (-3dB)
Video output
Number/type/format ................ 1 (2 if 134xi) analog RGBHV,
RGBS, RGsB
Connectors .................................... 6 BNC (2 x 6 if 134xi) female
1 15-pin HD female localmonitor
(150xi only) output (buffered)
Nominal level .............................. Unity, 0.725V p-p /50% peaking,
0.750V p-p /100% peaking
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
Sync
Input type ..................................... RGBHV TTL (±), RGBS TTL (±),
RGsB 0.3V (-), RsGsBs 1.3V (-)
Output type .................................. RGBHV (±), RGBS(±), RGsB (-)
Input level .................................... 2.0V to 5.5V p-p with ±0.2VDC
offset (max.)
Output level ................................. 4.0V to 5.0V p-p
Input impedance ......................... 10 kohms
Output impedance ...................... 75 ohms
Max. propagation delay ............. 48 nS
A-1
Appendix
Specifications — RGB 130xi, 134xi, 150xi
