Energizer AAA-850 (HR03) - Manual

AAA
Classification: ACCU Rechargeable
Chemical System: Nickel-Metal Hydride (NiMH)
Designation: IEC-HR03
Nominal Voltage: 1.2 Volts
Rated Capacity: 850 mAh (to 1.0 volts)
Based on 170 mA (0.2C) discharge rate
Typical Weight: 12.0 grams
Typical Volume: 3.8 cubic centimeters
Jacket: Plastic Label
0ºC to 40ºC
0ºC to 50ºC
Storage: -20ºC to 30ºC
Humidity: 65±20%
Value tolerances are ±20%.
general guidelines regarding environmental conditions.
Charge:
Operating and Storage Temperatures:
Operating at extreme temperatures,
will significantly impact battery cycle life.
100 milliohms 120 milliohms
Above values based on AC current set at 1.0 ampere.
Discharge:
To maintain maximum performance, observe the following
35
The impedance of the charged cell varies
with frequency, as follows:
Frequency (Hz) Impedance (milliohms)
1000
with state of charge, as follows:
Cell 1/2 Discharged Cell Charged
AC Impedance (No Load):
(tolerance of ±20% applies to above values)
(Charged Cell)
Important Notice
This datasheet contains information specific to battery chargers manufactured at the time of its publication.
©Energizer Holdings, Inc. - Contents herein do not constitute a warranty
Rechargeable AAA-850 (HR03)
Industry Standard Dimensions
Internal Resistance:
The internal resistance of the cell varies
Specifications
(mm)
Typical Discharge Characteristics
PRODUCT DATASHEET
0.9
1.0
1.1
1.2
1.3
1.4
0 3 6 9 12
Ce
ll V
olt
ag
e
Hours of Discharge
Typical Performance at 21ºC
85 mA
(0.1C)
170 mA
(0.2C)
0.9
1.0
1.1
1.2
1.3
1.4
0.0 0.5 1.0 1.5 2.0 2.5
Ce
ll V
olt
ag
e
Hours of Discharge
Typical Performance at 21ºC
0.425 A
(0.5C)
1.7 A
(2.0C)
0.85 A
(1.0C)
+ 44 (0) 208 920 2306
www.energizer.eu
European Region
10.50
9.50
3.80
Maximum
44.50
43.30
4.30
Minimum
0.80
Minimum
Form No. EBC - 8831EU Page 1 of 1
