Exmark TR23KC User Manual
Page 14
- 9 -
PART NO. 103-2248
LOCATION: Steering Console
PART NO. 1-403005
LOCATION: LH & RH Front Top
Surface of Mower Deck
PART NO. 1-543620
LOCATION: On Intake Screen Below Fuel Tank
PART NO. 1-543896
LOCATION: Under Engine Deck on
Wood Blocks for Shipping
PART NO. 98-5954
LOCATION: Under Belt Shields
Type A Anti-Scalp Rollers Only – See Figure 7
PART NO. 1-323540
LOCATION: Front of Mower Deck, Top Surface
