59

Press

ENT

to clear the alarm. If system is currently armed user will be prompted to

disarm the system first. Please refer to previous section for how to disarm the system.

Arm/Disarm the System using a Reader

The whole system can also be armed and disarmed using a keypad reader. (The

reader must have an integrated keypad, and the keypad and system reader settings

must be enabled on the controller in order to utilize this feature. Please refer to

subsection “Reader Setting” for instructions on enabling these features.) The part

number for the EverAccess keypad reader is ERK-871.

The user must first enter a command to get into the arm operation mode. (The

command is introduced in step 1 below.) In the arm operation mode, the yellow

LED on the ERK-871 will show the four different system modes outlined below:

Yellow LED Status

System ARM Status

OFF

Indicates that the system is disarmed

ON

Indicates that the system is armed

Flashing Slowly

Indicates that the system is in arm delay period

Flashing Quickly

Indicates that the system is armed and some alarm

input has triggered the alarm output.

The steps to arm or disarm the system at a keypad reader are as follows:

1.

Press

followed by the 6-pin ARM PIN. Press

again

2.

The reader is now in the arm operation mode.

3.

If the system is in disarmed mode (the yellow LED is OFF), press

to

arm the system. The system will enter the arm delay period (the yellow LED

will slowly flash).

Note: The system will not enter the arm delay period, if an alarm input is

active when the user attempts to arm the system. In other words, after

is pressed, if the yellow LED remains off, the system cannot

enter the arm delay period because an alarm input is active.

If the system is in armed mode (the yellow LED is ON) or in the arm delay

period (the yellow LED is flashing slowly), press

to disarm the system.

Then the system will enter the disarmed mode (the yellow LED will be off).

If the system is in alarm triggered mode (the yellow LED is flashing quickly),

press

to clear the alarm. Then the system will get into the armed mode

(the yellow LED will be on)

1

#

0

0

1

1

1

1

#

#
