Continued

MAV Plus Series

a / V M a t r i x S w i t c h e r S

Sync

(maV plus 88/128/168/816/1616 Video models)

Genlock connectors .. . . . . . . . . . . . 1 BNC female

Standards . . . . . . . . . . . . . . . . . . . . . . . . . NTSC 3.58, NTSC 4.43, PAL, SECAM

Sync

(maV plus 2412/2424/3216/3232 Video models)

Standards . . . . . . . . . . . . . . . . . . . . . . . . . NTSC 3.58, NTSC 4.43, PAL, SECAM

Audio

(audio models)

Routing
MAV Plus 88 Series

.. . . . . . . . . . . . . . 8 x 8 stereo matrix

MAV Plus 816 Series

. . . . . . . . . . . . . 8 x 16 stereo matrix

MAV Plus 128 Series

. . . . . . . . . . . . . 12 x 8 stereo matrix

MAV Plus 1212 Series

. . . . . . . . . . . 12 x 12 stereo matrix

MAV Plus 164 Series

. . . . . . . . . . . . . 16 x 4 stereo matrix

MAV Plus 168 Series

. . . . . . . . . . . . . 16 x 8 stereo matrix

MAV Plus 1616 Series

. . . . . . . . . . . 16 x 16 stereo matrix

MAV Plus 2412 Series

. . . . . . . . . . . 24 x 12 stereo matrix

MAV Plus 2424 Series

. . . . . . . . . . . 24 x 24 stereo matrix

MAV Plus 3216 Series

. . . . . . . . . . . 32 x 16 stereo matrix

MAV Plus 3232 Series

. . . . . . . . . . . 32 x 32 stereo matrix

Gain
MAV Plus 128 AV RCA

. . . . . . . . . . . Unbalanced output: 0 dB

All other models

. . . . . . . . . . . . . . . . . . . Unbalanced output: -6 dB; balanced output 0 dB

Frequency response . . . . . . . . . . . . 20 Hz to 20 kHz, ±0.05 dB

THD + Noise . . . . . . . . . . . . . . . . . . . . . . 0.03% @ 1 kHz at nominal level

S/N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >90 dB, balanced, at maximum output (21 dBu), unweighted

Crosstalk . . . . . . . . . . . . . . . . . . . . . . . . . . <-80 dB @ 1 kHz, fully loaded

Stereo channel separation . . . . >80 dB @ 1 kHz

CMRR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >75 dB @ 20 Hz to 20 kHz

Audio inPut

(audio models only)

Number / Signal type
MAV Plus 128 AV RCA

. . . . . . . . . . . 12 stereo, unbalanced

All other models

. . . . . . . . . . . . . . . . . . . 8, 12, 16, 24, or 32 stereo, balanced/unbalanced

Connectors
MAV Plus 128 AV RCA

. . . . . . . . . . . 12 pairs of RCA connectors

All other models

. . . . . . . . . . . . . . . . . . . (8, 12, 16, 24, or 32) 3.5 mm captive screw connectors, 5 pole

Impedance .. . . . . . . . . . . . . . . . . . . . . . . >10k ohm, balanced/unbalanced, DC coupled

Nominal level
MAV Plus 2412/2424 Series,
MAV Plus 3216/3232 Series

. . . . -10 dBV (316 mV)

All other models

. . . . . . . . . . . . . . . . . . . 0.1 dBu (775 mV)

Maximum level . . . . . . . . . . . . . . . . . . +19.5 dBu, (balanced or unbalanced) at 1% THD+N

Input gain adjustment . . . . . . . . . . -18 dB to +24 dB, adjustable per input by RS-232/422 or

front panel or by Ethernet

NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu

Audio outPut

(audio models)

Number / Signal type
MAV Plus 128 AV RCA

. . . . . . . . . . . 8 stereo, unbalanced

All other models

. . . . . . . . . . . . . . . . . . . 4, 8, 12, 16, 24, or 32 stereo, balanced/unbalanced

Connectors
MAV Plus 128 AV RCA

. . . . . . . . . . . 8 pairs of RCA connectors

All other models

. . . . . . . . . . . . . . . . . . . (4, 8, 12, 16, 24, or 32) 3.5 mm captive screw connectors, 5 pole

Impedance .. . . . . . . . . . . . . . . . . . . . . . . 50 ohms unbalanced, 100 ohms balanced

Gain error . . . . . . . . . . . . . . . . . . . . . . . . . ±0.1 dB channel to channel

Maximum level (Hi-Z) . . . . . . . . . . . >+21 dBu, balanced or unbalanced at 0.10%THD+N

Maximum level (600 ohm) . . . . . >+15 dBm, balanced or unbalanced at 0.10%THD+N

Output volume range . . . . . . . . . . . 0 to 64 (-85 dB to 0 dB) in 1 dB increments from steps 1 to 64, 35 dB

increment from step 0 to 1; default = 64 = 0 dB

control / reMote — Switcher

Serial control port . . . . . . . . . . . . . . . 1 RS-232 or RS-422, 9-pin female D connector

Baud rate and protocol . . . . . . . . . 9600 (default), 19200, 38400, 115200 baud (adjustable);

8 data bits, 1 stop bit, no parity

Serial control

pin configurations
RS-232 (all models)

. . . . . . . . . . . . . . 2 = TX, 3 = RX, 5 = GND

RS-422
(MAV Plus 2412/2424 Series,
MAV Plus 3216/3232 Series)

. . . 1 = Tx+, 2 = Tx-, 3 = Rx+, 4 = Rx-, 5 = Gnd

RS-422
(all other MAV Plus models)

. . . . . . 2 = TX-, 3 = RX-, 5 = GND, 7 = RX+, 8 = Tx+

Ethernet control port . . . . . . . . . . . 1 RJ-45 female connector

Ethernet data rate . . . . . . . . . . . . . . . 10/100Base-T, half/full duplex with autodetect

Ethernet protocol . . . . . . . . . . . . . . . . ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP, SMTP

Program control . . . . . . . . . . . . . . . . . Extron’s control/configuration program for Windows

Extron’s Simple Instruction Set (SIS

™

)

Microsoft

Internet Explorer, Telnet

GenerAl

Power .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 VAC to 240 VAC, 50/60 Hz, internal, universal

MAV Plus 88/128 Series: 30 watts
MAV Plus 816/1212/168/1616 Series: 48 watts
MAV Plus 2412/2424 Series video models: 2 (primary & redundant), 100 watts
MAV Plus 3216/3232 Series video models: 2 (primary & redundant), 120 watts
MAV Plus 2412/2424 Series, MAV Plus 3216/3232 Series S-video models:
2 (primary & redundant), 150 watts

Temperature / Humidity . . . . . . . . Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +113 °F (0 to +45 °C) / 10% to 90%, noncondensing

Rack mount . . . . . . . . . . . . . . . . . . . . . . Yes

Enclosure type . . . . . . . . . . . . . . . . . . . Metal

Enclosure dimensions
MAV Plus 88/128/1212 Series (all)
and 816/168/1616
Composite Video Series and
Stereo Audio Series

. . . . . . . . . . . . . . 3.5" H x 17.0" W x 9.4" D (2U high, full rack wide)

8.9 cm H x 43.2 cm W x 23.9 cm D

MAV PluS 88 throuGh 3232 SerieS
SPecificAtionS

Video

(Video models)

Routing
MAV Plus 88 Series

.. . . . . . . . . . . . . . 8 x 8 matrix

MAV Plus 816 Series

. . . . . . . . . . . . . 8 x 16 matrix

MAV Plus 128 Series

. . . . . . . . . . . . . 12 x 8 matrix

MAV Plus 1212 Series

. . . . . . . . . . . 12 x 12 matrix

MAV Plus 168 Series

. . . . . . . . . . . . . 16 x 8 matrix

MAV Plus 1616 Series

. . . . . . . . . . . 16 x 16 matrix

MAV Plus 2412 Series

. . . . . . . . . . . 24 x 12 matrix

MAV Plus 2424 Series

. . . . . . . . . . . 24 x 24 matrix

MAV Plus 3216 Series

. . . . . . . . . . . 32 x 16 matrix

MAV Plus 3232 Series

. . . . . . . . . . . 32 x 32 matrix

Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Unity

Bandwidth . . . . . . . . . . . . . . . . . . . . . . . . 150 MHz (-3 dB), fully loaded

0 - 10 MHz: no more than +0.1 dB to -0.1 dB
0 - 30 MHz: no more than +0.1 dB to -0.5 dB

Phase between I/Os
(MAV Plus 2412/2424 Series,
MAV Plus 3216/3232 Series)

. . . <1.28º at 3.58 MHz

Differential phase error . . . . . . . . 1.0º at 3.58 MHz and 4.43 MHz

Differential gain error . . . . . . . . . . 1.0% at 3.58 MHz and 4.43 MHz

Crosstalk . . . . . . . . . . . . . . . . . . . . . . . . . . -50 dB @ 5 MHz

Switching speed .. . . . . . . . . . . . . . . . 200 ns (max.)

Video inPut

(Video models)

Number / Signal type
MAV Plus 88/816 Series

. . . . . . . . . 8 RGsB, RsGsBs, HDTV, component video, S-video, composite video

MAV Plus 128 Series

. . . . . . . . . . . . . 12 RGsB, RsGsBs, HDTV, component video, S-video, composite video

MAV Plus 1212 Series

. . . . . . . . . . . 12 composite video

MAV Plus 168/1616 Series

. . . . . . 16 RGsB, RsGsBs, HDTV, component video, S-video, composite video

MAV Plus 2412/2424 Series
composite video models

. . . . . . . . . . 24 composite video

MAV Plus 2412/2424 Series
S-video models

.. . . . . . . . . . . . . . . . . . . 24 S-video, composite video

MAV Plus 3216/3232 Series
composite video models

. . . . . . . . . . 32 composite video

MAV Plus 3216/3232 Series
S-video models

.. . . . . . . . . . . . . . . . . . . 32 S-video, composite video

Connectors
MAV Plus 88/816 Series

. . . . . . . . . 8 x 3 BNC female for RGB/HDTV/component video,

8 x 2 BNC female for S-video,
8 BNC female for composite video

MAV Plus 128 Series

. . . . . . . . . . . . . 12 x 3 BNC female for RGB/HDTV/component video,

12 x 2 BNC female for S-video, 12 BNC female for composite video

MAV Plus 1212 Series

. . . . . . . . . . . 12 BNC female

MAV Plus 168/1616 Series

. . . . . . 16 x 3 BNC female for RGB/HDTV/component video,

16 x 2 BNC female for S--video, 16 BNC female for composite video

MAV Plus 2412/2424 Series
composite video models

. . . . . . . . . . 24 BNC female

MAV Plus 2412/2424 Series
S-video models

.. . . . . . . . . . . . . . . . . . . 24 x 2 BNC female

MAV Plus 3216/3232 Series
composite video models

. . . . . . . . . . 32 BNC female

MAV Plus 3216/3232 Series
S-video models

.. . . . . . . . . . . . . . . . . . . 32 x 2 BNC female

Nominal level . . . . . . . . . . . . . . . . . . . . 1 Vp-p for Y of component video and S-video, and for composite video

0.7 Vp-p for R-Y and B-Y of component video
0.3 Vp-p for C of S-video

Minimum / Maximum levels .. . Analog: 0.5 V to 2.0 Vp-p with no offset

Impedance .. . . . . . . . . . . . . . . . . . . . . . . 75 ohms

Return loss . . . . . . . . . . . . . . . . . . . . . . . <-30 dB @ 5 MHz

DC offset (max. allowable) .. . . . . . 1.5 V

External sync (genlock) . . . . . . . . . 0.3 V to 0.4 Vp-p

Video outPut

(Video models)

Number / Signal type
MAV Plus 1212/2412/2424 Series,
MAV Plus 3216/3232 Series
composite video models

. . . . . . . . . . 12, 16, 24, or 32 composite video

MAV Plus 2412/2424 Series,
MAV Plus 3216/3232 Series
S-video models

.. . . . . . . . . . . . . . . . . . . 12, 16, 24, or 32 S-video

All other models

. . . . . . . . . . . . . . . . . . . 8. or 16 RGsB, RsGsBs, HDTV, component video, S-video, composite video

(follows input type)

Connectors
MAV Plus 128/168 Series

. . . . . . . 8 x 3 BNC female for RGB/HDTV/component video,

8 x 2 BNC female for S-video,
8 BNC female for composite video

MAV Plus 1212 Series

. . . . . . . . . . . 12 BNC female

MAV Plus 2412 Series

. . . . . . . . . . . 12 BNC female for composite video

MAV Plus 816/1616 Series

. . . . . . 16 x 3 BNC female for RGB/HDTV/component video,

16 x 2 BNC female for S-video, 16 BNC female for composite video

MAV Plus 3216 Series

. . . . . . . . . . . 16 BNC female for composite video or 32 BNC female for S-video

MAV Plus 2424 Series

. . . . . . . . . . . 24 BNC female for composite video or 48 BNC female for S-video

MAV Plus 3232 Series

. . . . . . . . . . . 32 BNC female for composite video or 64 BNC female for S-video

Nominal level . . . . . . . . . . . . . . . . . . . . 1 Vp-p for Y of component video and S-video, and for composite video

0.7 Vp-p for R-Y and B-Y of component video
0.3 Vp-p for C of S-video

Minimum / Maximum levels .. . 0.5 V to 2.0 Vp-p (follows input)

Impedance .. . . . . . . . . . . . . . . . . . . . . . . 75 ohms

Return loss . . . . . . . . . . . . . . . . . . . . . . . <-30 dB @ 5 MHz

DC offset . . . . . . . . . . . . . . . . . . . . . . . . . . ±5 mV with input at 0 offset

Switching type . . . . . . . . . . . . . . . . . . . Vertical interval

306
