8 RCS In-Ceiling Manual
Earthquake Sound Corp. | www.earthquakesound.com
RCS-800 Specifications
9-5/8” (245mm)
8-3/8” (213mm)
8-9/16” (217mm)
3-7/8”
(98mm)
3-5/16” (85mm)
Frame Diameter:
9-5/8” (245mm)
Grille Diameter:
8-3/8” (213mm)
Cut-out Hole Diameter:
8-9/16” (217mm)
Mounting Depth:
3-7/8” (98mm)
Magnet Diameter:
3-5/16” (85mm)
Woofer Size:
8” (203mm)
Woofer Material:
Polypropylene
Tweeter Size:
1” (25mm)
Tweeter Material:
silk dome/NEO magnet
Power Handling RMS:
10 - 100W
Power Handling Max:
200W
Frequency Response:
45Hz - 20kHz
Sensitivity:
92dB
Impedance:
8-ohm
Crossover:
12dB/octave filter network with polyswitch
Finish:
White/Paintable
Weight:
3.04 lbs (1.38kg)
