R-5086
How To Order Repair Parts
...
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through
the distributor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your
equipment. Then determine the Part Number (not the Index Number) and the Description of each part from the following appropriate
illustration and list. Be sure to give all this information . . .
Heater Model Number
Part Description
Heater Serial Number
Type of Gas (Propane or Natural)
Part Number
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Index
Part
No.
Number
Description
Index
Part
No.
Number
Description
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
1
R-3436
REMOTE/OFF/ON SWITCH
2
CI-329
WIRE CHANNEL
3
CI-331
CHANNEL DIVIDER
4
CI-330
CASING SUPPORT
5
CI-307
REAR COVER
6
M-160
GASKET - VENT ELBOW
7
CI-332
AIR DROP ASSEMBLY
8
CI-364
RELIEF DOOR ASSEMBLY
9
CI-375
RELIEF DOOR BRACKET (2
REQUIRED)
10
CI-363
INNER TOP ASSEMBLY
11
CI-273
GLASS FRAME SUPPORT TOP
12
M-163
FLUE CONNECTOR TUBE GASKET (3
REQUIRED)
13
CI-274
SIDE SHIELD (2 REQUIRED)
14
CI-275
INNER BODY
15
CI-324
INTERNAL BAFFLE
16
CI-355
GLASS ASSEMBLY - SIDE (2
REQUIRED)
17
CI-356
GLASS ASSEMBLY - FRONT
18
CI-354
GLASS FRAME ASSEMBLY
19
R-2708
PIEZO IGNITOR
20
CI-143
VALVE COVER ASSEMBLY
21
CI-253
MAGNET ASSEMBLY (2 REQUIRED)
22
R-3318
GAS VALVE - NAT
22
R-3319
GAS VALVE - LPG
23
R-1259
3/8 NPT X 3/8 NPT STREET ELBOW
24
CI-016
MANIFOLD ASSEMBLY
25
P-86-38N
ORIFICE-NAT
25
P-86-54L
ORIFICE-LPG
26
* CI-008
LEG PAD-A (2 REQUIRED)
27
* CI-009
LEG PAD-B (2 REQUIRED)
28
CI-272
GLASS FRAME GUIDE
29
CI-362
INNER BOTTOM FACE ASSEMBLY
30
CI-145
DELAYED IGNITION RESET SWITCH
ASSEMBLY
31
R-4053
DOOR LATCH (2 REQUIRED)
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
32
CI-361
INNER BOTTOM ASSEMBLY
33
M-164
GASKET - MANIFOLD
34
M-157
GASKET - SEAL BRACKET
35
DVF-039
SEAL BRACKET
36
CI-257
AIR SHUTTER BODY
37
CI-023
BURNER BRACKET - RIGHT
38
R-3758
ADJUSTING SCREW
39
CI-025
AIR SHUTTER TOP
40
R-5278
BURNER
41
CI-022
BURNER BRACKET - LEFT
42
R-3473
THERMOCOUPLE
43
CI-018
PILOT TUBING
44
R-5285
THERMOPILE
45
R-3465
PILOT WITH ORIFICE (NAT ONLY)
45
R-3466
PILOT WITH ORIFICE (LPG ONLY)
46
CI-338
LOG SUPPORT ASSEMBLY
47
R-3642
FRONT LOG
48
R-3644
TOP LOG
49
R-3643
REAR LOG
NOT SHOWN
R-5143
PILOT ASSEMBLY - NAT. WITH
THERMOPILE THERMOCOUPLE
NOT SHOWN
R-5144
PILOT ASSEMBLY - LPG WITH
THERMOPILE THERMOCOUPLE
NOT SHOWN
CI-350
CABLE ASSEMBLY (DELAYED
IGNITION RESET SWITCH)
NOT SHOWN
R-3766
WIRE ASSEMBLY (DELAYED
IGNITION RESET SWITCH)
NOT SHOWN
R-3765-A
WIRE ASSEMBLY
NOT SHOWN
R-4505
TUBE OF FURNACE CEMENT
NOT SHOWN * CI-007
RETAINING TAB (4 REQUIRED)
NOT SHOWN * R-3747
LEVELING BOLT (4 REQUIRED
NOT SHOWN
CI-235
RESTRICTOR PLATE USED IN A
VERTICAL RISE BETWEEN 15' AND
25'
* PART IS INCLUDED IN THE HARDWARE PACKAGE AND IS
USED IN THE ASSEMBLY OF THE STOVE CASTING
