S1CA/S1HA ductless Split System Single-Zone
www.enviromaster.com
2
pHySiCAl dimenSiOnS
model
Size
A
B
C
09
24"
15"
36"
12
24"
15"
36"
18
32"
15"
36"
24
32"
15"
40"
30
38”
15”
44”
36
38”
15”
48”
Easy access interconnects on back of unit
S1C/S1H SpeCiFiCAtiOnS And dimenSiOnS
nOte:
All EMI products are subject to ongoing development. Design and specifications may change without notice.
1/2” Diameter Lag Holes
A
A
B
d
C
A
B
C
Electrical
Connections
mOunting dimenSiOnS
model Size
A
B
C
d
S1C/S1H
9, S1C/S1H2
4 ⅝”
14
11
/
16
”
3”
12
7
/
16
”
S1C/S1H
8, S1C/S1H4
4 ⅝”
22
11
/
16
”
3”
12
7
/
16
”
S1C
3, S1C6
7”
23
15
/
16
”
3”
12
7
/
16
”
