A u d i s s e y A P S 5 + 2 o w n e r s m a n u a l
11
CONNECTION METHOD USING
THE “SUBWOOFER” OUTPUT
(FIGURE 5)
AUDIO/VIDEO RECEIVER
SUBWOOFER
AMPLIFIER
NOTE:
ENSURE THAT ONE GOLDE
SHORTING BAR IS CONNECTED
AS SHOWN BETWEEN THE TWO
RED INPUT TERMINALS AND
ONE BETWEEN BLACK INPUT
TERMINALS.
SUBW
OOFER INPUT SELECT
OR SWITCH
MUST BE IN UPPER (180
°) OR LO
WER
(0
°) POSITION
SPEAKER
TERMINAL
RC
A INTERCONNECT FR
OM SUBW
OOFER
OUTPUT OF
A
V
RECEIVER OR PR
OCESSOR
CONNECT TO RIGHT SPEAKER
(AS SHOWN ABOVE FOR
LEFT SPEAKER)
