Description of the appliance, View of the appliance – Electrolux A 40100 GS User Manual
Page 12
Installation
12
1. Freezing tray (with 1 ice trays)
2. Freezing compartment
3. Storage compartments
(wire baskets)
4. Rating Plate
5. Control Panel
A) Green Indicator Light
B) Red Indicator Light
C) Yellow Indicator Light and
Fast Freeze Switch
D) Thermostat control knob
6. Defrost water outlet
7. Adjustable feet
8. Door gasket
9. Thermostat
10. Air grid
11. Condenser
12. Air circulation
13. Compressor
Description of the Appliance
View of the Appliance
