Project Name:
Architect:
Contractor: Phone:
Reseller: Phone:
PRODUCT NOTES
• Custom formats and sizes available upon request. Contact
Da-Lite for feasibility.
• Overall frame dimensions +/- ¼" (0.6 cm).
• Detailed dimensional drawing and installation instructions
available upon request.
• Specifications subject to change without notice.
• All Da-Lite surfaces are GREENGUARD GOLD Certified.
PRODUCT VIEW
Overall Frame Width =
Viewing Area + ¾"
24½"
Overall Frame Height =
Viewing Area + ¾"
1"
¾"
3⅜"
Overall Height
Including Tray =
Viewing Area + 1½"
WHEN ORDERING, MARK APPROPRIATE SELECTIONS
1. Select size from charts.
2. Select optional accessories:
Full length marker tray
_______ carton(s) of Whiteboard Cleaner - 2oz bottles, 12 bottles per carton
(one bottle already included with each screen)
_______ pack(s) of cleaning cloths - 12 cloths per pack (one cloth already
included with each screen)
_______ set(s) of markers - one each of red, blue, black, and green (one set
already included with each screen)
Note: Full Length Tray Width = Viewing Area Width – 1½"
