36” MOWER DECK

- 2 -

Ref.
No.

Qty.

Part No.

Description

Req'd.

Ref.
No.

Qty.

Part No.

Description

Req'd.

★

1-304267 Front Deck w/decals & dogleg....…1

1-323729 Powder metal bearing .................. 2

1-302235-01 Deck weldmt ................................. 1

323-4

3/8-16 x 3/4 HH capscrew ........... 8

1-302189-01 Baffle wldmnt, dogleg.................... 1

1-603843 Idler pulley (heavy duty)............... 1

322-2 Screw, 5/16-18 x 5/8 ..................... 7

∗

1-324265 Cutter Housing Complete ........... 2

32128-20 5/16-18 Whizlock nut................... 23

322-5 5/16-18 x 1 HH capscrew ............ 2

1-324408 Engagement arm w/bushing (36”). 1

1-633573 Guard, bottom ............................. 2

302-52

Grease Zerk, 1/8 NPT straight......2

32120-8 Retaining ring .............................. 2

302-19

Grease Zerk, 1/4-28 straight....... 1

∇

1-513016 Bearing ........................................ 4

1-323385

Knob, belt cover .......................... 4

1-323532 Cutter housing ............................. 2

1-809020 Quick pin, 10" caster ................... 2

1-303314 Spacer, 10” caster ....................... 8

3296-29 5/16-18 Nyloc hex nut ................. 2

1-323529 Tube, spindle ............................... 2

323-6

3/8-16 x 1 HH capscrew .............. 6

1-323528 Spacer ........................................ 2

3290-357

3/8-16 whizlock nut ...................... 14

1-303514 Flange , thrust bearing ............... 4

1-323748

Ring, push-on 7/16 ....................... 1

1-323339 Retaining washer, sheave ........... 2

98-5975 3/8 Disc spring washer ................. 7

∇

1-403183 Pulley........................................... 2

1-808280 5/16 x 1 Clevis pin ......................... 1

3219-6 5/8-18 UNF hex nut ..................... 2

1-303105 Yoke .............................................. 1

1-800861 5/8-18 x 8 HH Capscrew (Gr 5)... 2

1-806003 Cotter hairpin............................... 3

1-807267 Key, 1/4 x 3/16 x 1 1/4................. 2

32151-103 E-Ring for .875 rd. ....................... 1

1-323539 Spacer, blade drive...................... 8

323-10

3/8-16 x 2 capscrew.................... 1

1-513208 5/8 Spring disc washer ................ 2

1-633482 Blade, Notched air foil (36") ........ 2

1-303434

Engagement bushing .................. 1

1-613251 Blade, Solid air foil (36") .............. 2

1-303348

Eye bolt (left hand thread) ........... 1

•

1-633484 Blade, Mulching (36") .................. 2

1-303236

Turnbuckle body.......................... 1

1-633485 Blade, Low Lift (36") optional....... 2

1-303238

Eye bolt (right hand thread)......... 1

1-513338 Washer, special .......................... 2

1-322235

Assist arm (36”)........................... 1

3253-7 1/2 spring lockwasher ................. 2

322-10

Screw, 5/16-18 X 2 ...................... 1

3217-9 1/2-13 Hex nut............................. 2

1-323303

Assist arm linkage....................... 1

325-20 1/2-13 x 6 HH capscrew.............. 2

1-322153

Caster/mount, complete.............. 1

1-303352 Washer, spindle .......................... 1

1-302203

Caster wheel support w/bearings 2

1-513648 Wheel & tire, complete ................ 2

1-302194-01 Caster wheel support wldmnt...... 2

1-513807 Wheel & hub................................ 1

1-303334 5/16 Spring disc washer .............. 8

1-513808 Tire, 9 x 3.50-4 4-ply ................... 1

1-323533 Spacer ......................................... 2

1-513809 Roller bearing .............................. 1

1-634619 Housing w/Brg, Spacer and Ring 2

1-513810 Bushing........................................ 2

3256-3 Wshr, flat std 5/16 ....................... 1

1-323735 Drive belt (to blades) 36" Model .. 1

1-323715 Rod, brake 36”............................. 1

♦

1-803310 Setscrew, 5/16-18 x 3/8 .............. 2

1-323071

Spring.......................................... 1

322-6

5/16-18 x 1 1/4 HH capscrew ..... 9

1-323747

Spring, compression ................... 1

1-513547 Spacer, front caster..................... 2

1-323746 Spacer, flanged .......................... 2

1-303537 Stud, belt shield (short) ............... 2

3296-42 Nut, nyloc ¼ - 20 ......................... 2

1-303536 Stud, belt shield (long)................. 2

1-324372 Pad/spring assy........................... 1

1-302218 Kit,shield w/decals 36”................. 1

321-4 Screw, HHCap ¼-20 X 3/4 .......... 2

1-302213-01 Shield weldmt, 36" ..................... 1

1-403179 Tube, pivot................................... 1

1-323417 Washer, belt cover mount ........... 4

3256-23 Wshr, flt SAE 5/16 ....................... 1

1-322145-01 Fork wldmnt, caster..................... 2

32120-35 E-ring .......................................... 1

1-322154 Caster wheel assembly ............... 2

1-302233-01 Chute........................................... 1

3296-56 Nut, nyloc ¼-20 thin..................... 1

♦

Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews

•

Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK362(36”)

∗

Cutter housing complete includes sheave, washer, and nut and does not include blade.

★ Deck weldment does include welded in flow control baffles.

∇

Use antisieze on bore of sheaves & bearings

Exmark red touch up spray paint - P/N 1-850337
