17
Operating Instructions
CONTROL LOCK
To lock the controls between cycles, press and
hold the
control lock button for 5 seconds. Re-
peat to unlock the controls when you are ready to
operate the dryer. Use this feature to reduce the
likelihood of accidental operation by children.
STATUS DISPLAY
The estimated total cycle time will be displayed
when the cycle is selected. The estimated remain-
ing cycle time is displayed during the cycle.
DRUM LIGHT
The drum light will come on whenever the door is
opened to illuminate the drum during loading and
unloading. Closing the door turns off the light. The
drum light will automatically turn off if the door is
left open more than 3 minutes.
DRYING RACK
Use the drying rack to dry items which should not
be tumble dried. Fold down the metal support on
the back of the rack and slowly extend the rack
until the lock tabs click into place. Insert the rack
into the dryer drum, resting the back support on
the moisture sensor bars and the front legs on the
air grill.
Place items to be dried on top of the rack, leav-
ing space between items and not allowing them
to hang over the sides or through the holes. The
weight should not exceed 10 lbs (4.5 kg). Select
the
air (no heat) setting for items containing plas-
tic, foam rubber, rubber-like materials, feathers or
down.
When items are dry, remove the rack, push the two
center tabs to collapse the rack and fold up the
back support. Store the drying rack in a conve-
nient location.
REVERSIBLE DOOR
Your dryer is equipped with a reversible door. The
door can be hinged on the right or left side.
NOTE
For step-by-step instructions on DOOR
REVERSAL, refer to the Installation Instructions
supplied with this dryer.
Other Features
moisture sensing bars
Extend rack until tabs
click. Press tabs down
to collapse rack.
DRYING
SANITIZING
COOLING
WRINKLE REL. EXT. TUMBLE
CYCLE COMPLETE
CLEAN FILTER
STATUS DISPLAY
The following will also be displayed at the
appropriate times during the cycle:
