Page 41
Click The Page Number After Any Part Desciption To Veiw The Diagram Containing That Part.
B
BAND KIT.....29
BAR, BARRIER.....29
BEARING, BALL.....9
BEARING, BALL - 609.....25
BEARING, BALL - 6201.....25
BEARING, BALL - 6900.....25
BEARING, BALL - 6900Z.....25
BEARING, BALL 6001.....21
BEARING, NEEDLE.....21
BODY, AIR PURGE.....15
BODY, CARBURETOR.....15
BOLT 4X12.....11
BOLT 5X12.....29
BOLT 5X35.....25
BOLT 8X8.....25
BOX WRENCH -- 17X14.5mm.....39
BRACKET, CABLE.....15
BRACKET, HANDLE - LOWER.....29
BRACKET, HANDLE - UPPER.....29
BULB, PURGE.....15
C
CABLE, THROTTLE.....29
CAP, LIMITER.....15
CAP, SPARK PLUG.....19
CARBURETOR.....13
CARBURETOR -- WYK-186.....15
CASE, AIR CLEANER.....13
CASE, FAN.....9
CIRCLIP 12.....9, 25
CIRCLIP 22.....25
CIRCLIP 28.....9, 21
CIRCLIP 32.....25
CIRCLIP 42.....9
CIRCLIP, PISTON PIN.....21
CLAMP KIT.....29
CLIP.....7, 9
CLIP, SWIVEL.....15
COIL, IGNITION.....19
COLLAR 5.....5
CONICAL WASHER.....17
CONNECTOR, FUEL CAP.....7
CONTROL HANDLE KIT.....29
COVER.....29
COVER, CYLINDER.....5
COVER, MUFFLER.....5
COVER, PRIMER PUMP.....15
CRANKCASE KIT.....21
CRANKSHAFT ASY.....21
CUTTER.....23
CYLINDER.....21
D
DIAPHRAGM, PUMP.....15
DOWEL PIN.....9
DRIVESHAFT HOUSING ASY.....27
DRIVESHAFT, FLEXIBLE.....27
DRUM, CLUTCH.....9
DRUM, STARTER.....11
E
E-RING 4.....11
F
FAN COVER ASY.....9
FILTER KIT.....37
FILTER, AIR.....13
FILTER, FUEL.....7
FIXTURE, MAIN PIPE.....9
FLANGE NUT 8.....19
FLANGE, SHIELD.....23
FLYWHEEL.....19
FRONT HANDLE ASY.....29
FUEL TANK CAP ASY.....7
G
GASKET KIT.....33
GASKET, CRANKCASE.....21
GASKET, CYLINDER.....21
GASKET, EXHAUST.....17
GASKET, FUEL CAP.....7
GASKET, INTAKE.....13
GASKET, METERING DIAPHRAGM.....15
GASKET, PUMP.....15
GASKET/DIAPHRAGM KIT.....15
GEAR CASE ASY.....25
GEAR SET.....25
GRIP, HANDLE.....29
GRIP, STARTER.....11
GROMMET.....19
GROMMET, FUEL.....7
GUARD, DEBRIS.....13
GUARD, TOP.....5
GUIDE, EXHAUST.....17
GUIDE, ROPE.....11
H
HANDLE, FRONT.....29
HEX BAR -- 10mm.....39
HOOK ASY.....29
HOUSING, GEAR.....25
I
IGNITION SWITCH ASY.....29
INSULATOR.....13
K
KNOB.....29
KNOB, FASTENER.....13
L
LABEL - CAUTION -- HOT.....5
LABEL - CAUTION -- SPANISH.....27
LABEL - CHOKE.....13
LABEL - ECHO.....11
LABEL - HANDLE LOCATION.....27
LABEL - MODEL.....9
LABEL - MODEL -- SRM-260.....31
LABEL - MODEL -- SRM-260S.....31
LABEL - MODEL -- SRM-260SB.....31
LABEL - MODEL -- SRM-260U.....31
LABEL - MODEL -- SRM-261.....31
LABEL - MODEL -- SRM-261S.....31
LABEL - MODEL -- SRM-261SB.....31
LABEL - MODEL -- SRM-261T.....31
LABEL - MODEL -- SRM-261U.....31
LABEL - PIPE LOCATION.....27
LABEL - SPARK PLUG -- BPM-8Y.....19
LABEL - SPARK PLUG -- BPMR-8Y.....19
LABEL, CAUTION - CANADA.....27
LABEL, CAUTION - US.....27
LEAD, GROUND.....19
LEAD, IGNITION.....19
LEVER, METERING.....15
LEVER, THROTTLE LOCKOUT.....29
LID, AIR CLEANER.....13
LINER, FLEXIBLE.....27
LOCKING BAR -- 5X120mm.....39
LOCKOUT, THROTTLE TRIGGER.....29
L-WRENCH -- 3mm.....39
L-WRENCH -- 4mm.....39
L-WRENCH -- 5mm.....39
M
METERING, DIAPHRAGM.....15
MUFFLER.....17
N
NEEDLE, HIGH SPEED.....15
NUT.....11
NUT 5.....23, 29
NUT 6.....29
NUT 8.....11
O
P
PACKING, RING.....15
PAWL, STARTER.....11
PIN, METERING LEVER.....15
PIN, PISTON.....21
PIPE, FUEL - 3X6X170mm.....7
PIPE, RETURN - 3X6X80mm.....7
PIPE, VENT - 3X6X115mm.....7
PISTON KIT.....21
PLASTIC SHIELD KIT.....23
PLATE, ADAPTER (UPPER).....25
PLATE, EYE.....17
PLATE, PREVENT.....13
PUMP BODY ASY.....15
R
REPAIR KIT.....15
RING, PISTON.....21
ROPE, STARTER - 3X850mm.....11
S
SCREEN, INLET.....15
SCREEN, MUFFLER.....17
SCREW.....11
SCREW 3X10.....29
SCREW 4X10.....17
SCREW 5.....29
SCREW 5X10.....19, 25
SCREW 5X12.....5
SCREW 5X14.....29
SCREW 5X16.....5, 7, 19, 23
99922203964
- 41 -
REVISED 10/11/07
Part Description Index
