P a g e | 171
FIGURE 206
•
Checkmark channels 2, 3 and 4 in the column below In 1 (see FIGURE 206 ). This routes sound from the first
incoming Skype caller to all Aux 1 output channels except channel 1.
•
Open the audio configuration pane Input 14 and, in the Routing tab, clear the Aux 1 matrix.
FIGURE 207
•
This time, checkmark channels 1, 3 and 4 in the column below In 1 . This routes sound from the second
incoming Skype caller to all Aux 1 output channels except channel 2.
•
Repeat the steps above for audio inputs 15 and 16, omitting the Aux 1 checkmarks under In 1 for channels
3 and 4, respectively.
That’s it – you’ve go t the perfect mix minus configuration for return to your four Skype callers. All you need
to do now is finish up by configuring the TalkShow returns on the VS4000 system.
