DIRECT WALL MOUNTING
TV MOUNT MOUNTING
TV
MONTAGE MURAL DIRECT • MONTAJE DIRECTO EN LA PARED • DIREKTE WANDBEFESTIGUNG • MONTAGGIO DIRETTO A PARETE • MONTAGEM DIRETA NA PAREDE • 直接墙上安装
MONTAGE POUR TÉLÉVISEURS • MONTAJE DEL SOPORTE DEL TELEVISOR • TV-WANDBEFESTIGUNG • MONTAGGIO DEL SUPPORTO DEL TELEVISORE • MONTAGEM EM SUPORTE DE TV • 电视架安装
TV
SOUND BAR
Figure 1 Figure 2
SOUND BAR
BRACKET NOT INCLUDED
SUPPORT MON INCLUS
NO SE INCLUYE EL SOPORTE
HALTERUNG NICHT IM LIEFERUMFANG ENTHALTEN
STAFFA NON INCLUSA
SUPORTE NÃO INCLUÍDO
不包括支架
1
2 3
WALL MOUNT PROCESS:
1) Included wall mount screws
screw into back of bar.
2) Brackets screw into wall with
no. 12 pan head/m6 pan head screw. (Not included)
3) Wall mount screws hang bar on bracket.
