UPA-2 Technical Specifi cations
Rated Power Output: (All Channels Driven @ 1Khz, 115VAC/ 60HZ supply, THD noted)
Channels 1-2 125 Watts into 8 Ohms (0.04%THD)
225 Watts into 4 Ohms (0.04%THD)
Frequency Response:
20-20Khz: +/-0.1dB
10-100Khz: +1/-3dB
Total Harmonic Distortion (THD): (80kHz measurement bandwidth)
Channels 1-2: <0.040%
Signal-to-Noise Ratio: >100dB, Unweighted (Full Output Reference)
DC Offset: <1mV
Crosstalk: >80dB
Damping Factor: Approximately 200 into 8 Ohms
Input Sensitivity Range (Gain):
Channels 1-2 31dB
Input Impedance (RCA Input): 23.5K Ohm
External Trigger Input: 5~12 VDC, center tip of 3.5mm jack is positive
Clearance for ventilation (Back): Minimum 2” / 50 mm
Electrical Power Requirement: 350 watts @ 115VAC when driven into 8 Ohms
Electrical Power Consumption: 4 Watts (Standby) and 30 Watts (Idle)
Raw Weight:
Shipping Weight: 39lbs /17.7kg
Dimensions: 17” W x 3.46” H x 16.7” D
432mm W x 88mm H x 423mm D
30lbs/ 13.6kg
External Trigger Output: 12VDC, 500mA max
