Electrolux Dishwashing
Hood Type
Internet: http://www.electrolux.com/foodservice
IDA010
2012-07-26
Subject to change without notice Convertible to 230 V / 1+N / 50 Hz;
230 V / 3 / 50 Hz
230 V / 1+N / 50 Hz;
230 V / 3 / 50 Hz
230 V / 1+N / 60 Hz;
230 V / 3 / 60 Hz
Supply voltage 400 V, 3N, 50 400 V, 3N, 50 400 V, 3N, 60
Net weight - kg. 86 86 98
Noise level - dBA <68 <68 <68
total power 9.9 9.9 9.9
Power - kW
Boiler elements - kW 9 9 9
Boiler capacity - lt. 12 12 12
water consumption - lt./cycle 3 3 3
temperature during rinse - °C 80-90 80-90 80-90
duration - sec. 16 16 16
Hot rinse cycle
electrical elements - kW 2.2 2.2 2.2
power pump - kW 0.8 0.8 0.8
tank capacity - lt. 42 42 42
temperature -°C 55-65 55-65 55-65
Washing cycle
height 409 409 409
depth 560 560 560
width 585 585 585
Cell dimensions - mm
height 1515 1515 1515
depth 833 833 833
width 748 748 748
External dimensions - mm
Door/hood thickness Single Single Single
Basket capacity/h 67 67 67
Dishes capacity/h 1200 1200 1200
Duration cycles - sec. 54/90/150 54/90/150 54/90/150
N° of cycles 3 3 3
Rinse aid dispenser ● ● ●
Detergent dispenser ●
hardness - °f 7-14 7-14 7-14
temperature - °C 50 50 50
Water supply
TECHNICAL DATA
NHT
505051
NHTD
505052
NHT60
505053
• 304 stainless steel boiler with
higher welding protection
improves the resistance against
corrosion with chlorinated water.
• PVC water supply hose with
metal connections resistant to
high water pressure.
• The IPX4 water protection.
• Pre-arranged for on-site HACCP
implementation and Energy
Management device.
FLEXIBILITY AND ERGONOMICS
• The incorporated Soft Start
feature offers additional protection
to delicate items such as
glassware and crockery and
increases wash pump reliability.
• Three phase electrical
connection, convertible on-site.
• Hood handle on three sides thus
facilitating the use in corner
installation.
• Suitable to be connected to
specific pre-wash tabling, service
entry and exit tabling and roller
conveyor tabling – included in
Electrolux Professional Handling
System range.
• The machine will start with the
closing of the hood and stops when the hood is opened.
• Open hood on the back side to
prevent steam blasts to the
operator.
• All machines are pre-arranged to
accept external dispensers.
EASY ON THE ENVIRONMENT
• 97% recyclable by weight.
• CFC free packaging.
• Low noise level.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
• In compliance with
H
requirements.
* Duration cycle: declared actual cycle
duration times can extend when water
supply temperature is lower than
indicated.
