5" & 8" skid steer specs
Models CH500H (74500), CH800H (74800)
SKID-STEER MOUNT
•CH500H (74500) fits skid steers with stan-
dard or high-flow hydraulics
•CH800H (74800) fits skid steers with high-flow hydraulics
•Two mounts, so chipper can be mounted with feed
table facing forward or to the curbside
•Easy to attach just connect chipper to the SAE J2513 Quick-
Tach, attach the hydraulic hoses, and you are ready to go
HYDRAULIC FEED
•Four-position manual valve control ( Re-
verse-Neutral-Forward-Reverse).
•Infinite speed settings with turn of a handle
•Automatic feed control, which slows the feed
roller if the disc starts to slow down
CHIPPER DISC
•CH500H (74500) has a 20" x 1.25" [51cm x
3.175cm] 140lb. [63.5kg] disc. Machined.
•CH800H (74800) has a 30" x 1.25" [76cm x 3.175cm]
275 lb. [125kg] disc. Machined & Balanced.
FOUR CHIPPING BLADES
•Reversible heat-treated chipper steel blades, with chrome content.
•Blades are mounted 90 degrees to each other
for smoother operation and less vibration.
FOUR EDGE ADJUSTABLE ANVIL/CUTTER BAR
To insure good chipping ability.
CONTINUOUS CHIPPING SIZE
•CH500H (74500) has a 5.5" x 7" [14cm x 18cm] chipper open-
ing for side limbs, and wil chip up to 3" limbs continuously.
•CH800H (74800) has a 9" x 9" [23cm x 23cm] chipper open-
ing for side limbs, and will chip up to 5" limbs continuously.
EASY ACCESS DISC
The disc is accessible through the hinged disc cov-
er, which exposes one half of the disc for easy access
to the chippping blades and for easy clean out.
INTEGRATED BLOWER
Put the chips where you want them with the dedicated blower.
360° rotating, 6" [15cm] (74500) or 8" [20cm] (74800) di-
ameter steel tubing with adjustable deflector cap allows you
to put the chips where you want them the first time.
HEAVY-DUTY CONSTRUCTION
OTHER FEATURES:
• Slip-resistant step pads for entry or exit from skid-steer
• Weatherproof owner's manual box
Weight
• Model CH500H (74500) – 1145 lbs [520kg]
• Model CH800H (74800) – 1525 lbs [693kg.]
Safety
• Safety chains standard
• Meets all applicable ISO and CE safety standards.
