NOMENCLATURE OF PARTS
* If a decal cannot be read, a new one can be
ordered from your ECHO dealer.
23
20
15
16
17
19 18
14
5
4
7
6
9
10
11
12
13
3
2
1
X524-002000
890191-30131
X503-009050
8
21
22
Part Number X503-009050
WARNING!! Read and follow all safety
precaution in the instruction manual.
Failure to follow instructions could
result in serious personal injury.
CS-530
TO AVOID KICKBACK
1. Hold the chain saw firmly with
both hands.
2. Don’t let the nose of the guide
bar contact any obstruction.
3. Tip contact may suddenly move the
guide bar upward and backward,
which may cause serious injury.
Part Number 890191-30131
Part Number X524-002000
REPLACEMENT BAR AND CHAIN
GUIDE BAR* CHAIN*
PART NO. TYPE LINKS
16” 16F0MD3366 OREGON 95VP 66
18” 18F0MD3372 OREGON 95VP 72
20” 20F0MD3378 OREGON 33SL 78
*Or equivalent
Note: There may be other replacement
components for achieving kickback
protection. For details, please refer
to the chain and bar combination
sheet shown in the instruction manual.
