Basic Specifications:
Description: Neo-Flex™ LCD Arm
Brown Box Part Number: 45-174-300 (silver)
Attachment Options:
• Desk clamp: mounts to surfaces up to 2" (51 mm) thick
• Grommet: mounts through holes up to 2" (51 mm) wide,
to surfaces up to 1-3/4" (44.5 mm) thick. Grommet must be
center mounted on the through hole.
Easily attach your LCD to the arm with
four screws. Then position the height and
angle of the LCD for maximum comfort and
productivity.
Gently press button and smoothly lift your
LCD into the position that fits your needs.
Cables are guided along the underside of arm
for a clutter-free desk.
Robust desk clamp base uses little space yet
ensures stability even as the LCD is adjusted
(optional grommet mount kit included).
The Neo-Flex LCD Arm is compatible with
LCDs that are VESA compliant. Simply remove
the existing base of the LCD and attach the
LCD to the Arm.
Range of Motion:
180° up/down
LCD tilt
180° right/left
LCD tilt
360° LCD
portrait/landscape
rotation
8" (203 mm) arm
height adjustment 360° arm side-to-side range
LCD Interface Options:
• Accommodates VESA MIS-D, 100/75, C compliant LCDs
Weight Capacity: 18 lbs (8.2 kg)
Shipping Weight: 9 lbs (4.09 kg)
Warranty: 3-year
Content is subject to change
without notification.
