Installation
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
GREEN AND YELLOW
EARTH
BLUE
NEUTRAL
BROWN
LIVE
If you fit your own plug, the colours of the wires in the mains lead of your
appliance may not correspond with the markings identifying the terminals in
your plug, proceed as follows:
• Connect the green and yellow (earth) wire to the terminal in the plug which is
marked with the letter ”E” or the earth symbol ( ) or coloured green and
yellow.
• Connect the blue (neutral) wire to the terminal in the plug which is marked
with the letter ”N” or coloured black.
• Connect the brown (live) wire to the terminal in the plug which is marked
with the letter ”L” or coloured red.
13 AMP
GREEN & YELLOW
13 AMP FUSE
BROWN
CORD CLAMP
BLUE
