Installation – Enviro Kodiak 1200 Fireplace Freestanding User Manual
Page 44
44
Fan
White
Black
Black
Black
Fan
temperature
sensor
White
Fan
controller
Power Supply
Black
Black
Fan
White
Black
Fan
temperature
sensor
White
Black
Power Supply
Fan
controller
Installation
Figure 54: Freestanding Fan Kit Wiring Diagram.
DO oil the fan bearings regularly.
DO NOT cut or remove the grounding prong from the plug.
DO NOT route the power cord beneath the heater.
WARNING: This appliance is equipped with a three-prong (grounding) plug for your protection against
shock hazard and should be plugged into a properly grounded three-prong receptacle.
Figure 55: Fireplace Insert Fan Kit Wiring Diagram.
