ORDERING INFORMATION
SPECIFICATIONS
Wavelength range (nm)
1260 to 1675 (O to U band)
Measurement range (ps)
0 to 115
Sensitivity (dBm)
—45
1
Measuring time (s)
4.5 (for any PMD value)
Absolute uncertainty (accuracy)
2
(ps)
± (0.020 + 2 % of PMD)
Allows measurement through EDFA
Yes (above 120 EDFAs)
GENERAL SPECIFICATIONS
Temperature
operating
0 °C to 40 °C
(32 °F to 104 °F)
storage
–40 °C to 70 °C
(–40 °F to 158 °F)
Relative humidity
0 % to 93 % non-condensing
Size (H x W x D) (module only)
9.6 cm x 7.6 cm x 26.0 cm
(3
3
/
4
in x 3 in x 10
1
/
4
in)
Weight (module only)
1.5 kg
(3.4 lb)
Note:
1. Typical, for C-band. May be increased with averaging. With the FLS-5800, the typical dynamic range is 47 dB.
2. For C-band, assuming averaging over all states of polarization.
PMD Analyzer
CD/PMD Analyzer Source
Polarized Light Source
FTB-5500B-
XX
FLS-58
XX
-
XX
FLS-110-
XX
P-
XX
Connector
*
EI-EUI-
28
= UPC/DIN 47256
EI-EUI-
76
= UPC/HMS-10/AG
EI-EUI-
89
= UPC/FC narrow key
EI-EUI-
90
= UPC/ST
EI-EUI-
91
= UPC/SC
EI-EUI-
95
= UPC/E-2000
EA-EUI-
28
= APC/DIN 47256
EA-EUI-
89
= APC/FC narrow key
EA-EUI-
91
= APC/SC
EA-EUI-
95
= APC/E-2000
Example: FTB-5500B-EI-EUI-89
Model
FLS-110-
02
P = 1310 nm LED
FLS-110-
03
P = 1550 nm LED
Connector
*
58
= FC/APC narrow key
89
= FC/UPC narrow key
91
= SC/UPC
EI-EUI-
28
= UPC/DIN 47256
EI-EUI-
76
= UPC/HMS-10/A
EI-EUI-
89
= UPC/FC narrow key
EI-EUI-
90
= UPC/ST
EI-EUI-
91
= UPC/SC
EI-EUI-
95
= UPC/E-2000
EA-EUI-
28
= APC/DIN 47256
EA-EUI-
89
= APC/FC narrow key
EA-EUI-
91
= APC/SC
EA-EUI-
95
= APC/E-2000
Example: FLS-110-02P-EI-EUI-89
Connector
*
EI-EUI-
28
= UPC/DIN 47256
EI-EUI-
76
= UPC/HMS-10/AG
EI-EUI-
89
= UPC/FC narrow key
EI-EUI-
90
= UPC/ST
EI-EUI-
91
= UPC/SC
EI-EUI-
95
= UPC/E-2000
EA-EUI-
28
= APC/DIN 47256
EA-EUI-
89
= APC/FC narrow key
EA-EUI-
91
= APC/SC
EA-EUI-
95
= APC/E-2000
Example: FLS-5803-EI-EUI-89
Model
FLS-58
03
= 1550 nm SuperLED
FLS-58
04
= 1625 nm SuperLED
FLS-58
34
= 1550 nm and 1625 nm SuperLEDs
Safety
Standard Accessories
21 CFR 1040.10
Class I Laser Product
User Guide, Certificate of Calibration, connector cleaners.
IEC 60825-1: 2001
Class 1 Laser Product
*
EXFO Universal Interface is protected by US patent 6,612,750.
