1 3
2 4
INSTRUCTIONS TO REPLACE LIGHT TUBE LAMP (Reference diagrams above.)
1. Extend and hold light tubes, turn cap clockwise and pull to remove cap.
2. With light tube three quarters of full extension, insert index finger in light source hole at base of
lamp, gently push bulb and socket through the cap's hole and replace lamp.
3. Reset socket with white mark on top, opposite light source hole, gently force lamp and socket
back into light tube to a firm fit. (It may be necessary to joggle socket with one hand and guide
with finger in light source hole to get proper placement.)
4. Hold light tube and snap cap back into place. Twist cap counter-clockwise firmly.
NOTE: Replacement lamp is a standard 120 volt, 4 watt incandescent lamp. (Christmas tree lamp)
Thank you for considering and
purchasing an ETA Conditioned
Power Distribution unit.
By listening to our large base
of present and past customers, and
drawing upon many years of experi-
ence in design and solving high
amperage lighting and conditioned
power distribution needs, ETA has
developed an extensive line of
Audio Conditioned Power Distribu-
tion units to protect a broad range of
sensitive electronic equipment.
ETA offers a complete line of
power conditioning units in addition
to the PD9L model. The complete
product line includes 12 models of
professional Audio Conditioned
Power Distribution units that are
UL listed and include features such
as sequential power up/power down,
high amperage output, and AC
voltage regulator units.
SPECIFICATIONS:
Input Voltage 120V AC
Spike protected Line to neutral, neutral
to ground, line to ground
UL 1449 suppressed 395V
voltage rating
Response time <1NS Typical
Operating temp. range – 40° to +158° F
Maximum energy dissipation 450 joules (3 x 150)
Maximum surge current 12000A
Maximum surge voltage 6000V
Noise attenuation Transverse up to 20 dB
(1.5 kHz to 200 mHz )
