Ametrix, C-scroll
SUSPENDED
1260
COOPER LIGHTING
AMETRIX
™
c-Scroll
S M A L L
• Extruded aluminum
housing
• Die-cast aluminum
end caps
• Integrated visor option -
solid, perf or opal window
• Die-formed 94% reflective
dual-finish anodized
aluminum reflector
• Gasketed hinging
doorframe - indoor
toolless entry
• PointGrab
™
adjustment
Remote
O R D E R I N G I N F O R M A T I O N
S A M P L E N U M B E R : S N - S I - P - 1 - M 1 5 0 - 1 2 0 - W - P P 1 2
Product
❑ SN
c-Scroll
No Visor
❑ SS
c-Scroll
Solid Visor
❑ SO
c-Scroll
Opal Visor
❑ SP
c-Scroll
Square
Perf Visor
Size - Indoor
❑ SI
Small Indoor
Lens
❑ C
Clear
❑ P
Micro-prismatic
❑ U
U.V.*
❑ N
None**
No. of Lamps
❑ 1
1 Lamp
Wattage
❑ 026
26W (F)
❑ 039
39W (E, M)
❑ 070
70W (E, M)
❑ 100
100W (T)
❑ 150
150W (E, M, T)
❑ 250
250W (T)
* Not available with
all sources or options.
(Consult factory)
** Only available for
fluorescent option.
Specifications and
dimensions subject to
change without notice.
Voltage
❑ 120
120V (T)
❑ 277
277V
❑ 347
347V
Finish
❑ W
White
❑ S
Silver
❑ B
Bronze
❑ C
Custom
(Consult factory)
Mounting
❑ PP12
Pendant 12”/Remote
❑ PP18
Pendant 18”/Remote
❑ PP24
Pendant 24”/Remote
❑ PP30
Pendant 30”/Remote
❑ PS12
Pendant Swivel
12”/Remote
❑ PS18
Pendant Swivel
18”/Remote
❑ PS24
Pendant Swivel
24”/Remote
❑ PS30
Pendant Swivel
30”/Remote
❑ P1R30
Uplight Pendant
30”/Remote
❑ P2R30
Two Uplight
Pendant
30”/Remote
❑ P4R30
Four Uplight
Pendant
30”/Remote
Modification
❑ MOD
Provide description
of the modification.
(Consult factory)
Accessories
❑ L45
45˚ Cross Blade
Louver
❑ L25
25˚ Cross Blade
Louver
Lamp/Ballast Type
❑ F
Fluorescent
(Electronic)
❑ T
Tungsten
Halogen
❑ E
Metal Halide*
(Electronic)
❑ M
Metal Halide
(Magnetic)
30"
[762mm]
Specify
Length
(Consult factory
for maximum length)
9-7/8" [251mm]
See Lamp Chart
LAMP CHART - Remote
SOURCE
WATTAGE
LENGTH
Tungsten
100
10-3/4"
150
13"
250
13"
Metal Halide
39
10-3/4"
70
13"
150
13"
Fluorescent
26
13"
