1939L 19” LCD Rear-Mount Touchmonitor Specifications
Model
1939L
Case/bezel color
Steel/black
Display type
Active matrix TFT LCD
Display size
19.0” diagonal
Useful screen area
Horizontal/vertical
14.8” (376 mm)/11.9” (301 mm)
Monitor dimensions
Width: 16.3” (415 mm)
Height: 13.5” (343 mm)
Depth: 2.0” (51 mm)
Optimal (native) resolution
1280 x 1024
Other supported resolutions
1280 x 1024 60, 70, 75 Hz; 1280 x 960 60 Hz; 1152 x 864 75 Hz; 1024 x 768 60, 70, 75 Hz; 1024 x 768 65 Hz (Sun);
832 x 624 75 Hz (Mac); 800 x 600 56, 60, 72, 75 Hz; 720 x 400 70 Hz; 720 x 350 70 Hz; 640 x 480 60, 72, 75 Hz;
640 x 480 66 Hz (Mac)
Colours
16.7 million colours
Brightness (typical)
LCD panel
250 cd/m
2
LCD panel with IntelliTouch
230 cd/m
2
LCD panel with Surface Capacitive 212 cd/m
2
Response time (typical)
Rise/fall
13 msec/7 msec
Viewing angle (typical at a CR>10)
Horizontal (left/right)
85°/85°
Vertical (up/down)
85°/85°
Contrast ratio
1000:1
Input video format
RGB analog
Input sync format
Separate H & V sync, composite sync, and sync-on-green
Input video signal connector
Mini D-Sub 15-Pin VGA type
Scanning frequency
Horizontal/vertical
31.5 - 80.0 kHz/56.3 - 75 Hz
Power dissipation
Monitor only
46 W (max.)
Monitor and power brick
50 W (max.)
Power supply
External AC to DC power brick is provided
Input voltage requirement
Monitor input
+12VDC +/- 5%, 3.2A typical, 3.8A maximum
AC to DC power brick input
100-240 VAC, 50/60Hz
Temperature
Operating/storage
0°C to 40°C/-20°C to 60°C
Humidity (non-condensing)
Operating/storage
20% to 80%/10% to 90%
Mean time between failures
(MTBF)
50,000 hours demonstrated
Backlight lamp life (typical)
40,000 hours to half brightness
Weight (approx.)
Actual/shipping
5.2 kg (11.5 lbs)/7.3 kg (16.1 lbs)
Other Features
Digital on-screen display (OSD); Fully RoHS compliant; Patent pending bezel seal and patented touch technology
Mounting options
75 mm and 100 mm VESA mounting; rear mount with or without bezel, mounting brackets (included)
User’s controls
OSD buttons: menu, left, right, select, power; OSD: contrast, brightness, H/V position, RGB (color temp), clock,
phase, recall, language (English, German, Spanish, Japanese, French); OSD disable/enable and power disable/enable
Warranty
Touchmonitor: 3 years (Europe only. Contact your local Elo office,
distributor or reseller for local warranty conditions)
Touch interface
Serial and USB
Agency certifications
UL, cUL, SEMKO, CB, TÜV-T, CE/FCC/VCCI/IC/C-TICK (Class B)
