Specifications
General
Name Zenmuse XT 2
Dimensions
25 mm lens: 123.7Ч112.6Ч127.1 mm
Other lens versions: 118.02Ч111.6Ч125.5 mm
Weight
25 mm lens: 629 g
Other lens versions: 588 g
Gimbal
Angular Vibration Range ±0.01°
Mount Detachable
Controllable Range Tilt: +30° to -90°, Pan: ±320°
Mechanical Range Tilt: +45° to -130°, Pan: ±330°, Roll: -90° to +60°
Max Controllable Speed Tilt: 90°/s ， Pan: 90°/s
Camera (Thermal)
Thermal Imager Uncooled VOx Microbolometer
FPA/ Digital Video Display Formats 640Ч512; 336Ч256
Digital Zoom
640×512: 1x, 2x, 4x, 8x
336×256: 1x, 2x, 4x
Pixel Pitch 17 μm
Spectral Band 7.5-13.5 μm
Full Frame Rates 30 Hz
Exportable Frame Rates <9 Hz
Sensitivity (NEdT) <50 mk @ f/1.0
Scene Range (High Gain)
640×512: -25° to 135℃
336×256: -25° to 100℃
Scene Range (Low Gain) -40° to 550℃
File Storage microSD card*
Photo Format JPEG, TIFF, R-JPEG
Video Format
8 bit: MOV, MP4
14 bit: TIFF Sequence, SEQ**
Camera (Visual)
Sensor CMOS, 1/1.7", Effective Pixels: 12 M
Lens
Prime lens
Focus at 8 mm, FOV 57.12 °× 42.44 °
Digital Zoom 1x, 2x, 4x, 8x
Photo Formats JPEG
Video Formats MOV, MP4
Video Resolutions
4K Ultra HD: 3840×2160 29.97p
FHD: 1920×1080 29.97p
