ENGLISH
1. Parts identification (standard delivery)
2
5
6
7
8
9 11 12
13
1
14
15
16
17
18
19
10
3
4
Front
1 Upper housing door
2 Setting knob for band saw
blade tension
3 Upper band saw wheel
4 Setting knob for blade guard
5 Blade guard
6 Band saw blade
7 Saw table
8 Fence guide extrusion,
graduated
9 Lower band saw wheel
10 Chip case
11 Rip fence
12 Lower housing door
13 On/Off switch with emergency
stop
Rear
14 Setting knob for blade tracking
adjustment
15 Motor
16 Machine base
17 Dust extraction port
18 Setting knob for drive belt
19 Table insert
